Wheel Tractor Type and 4WD By Wheel Mini Farm Tractor
- QINGDAO PORT
- T/T Credit Card
You May Like
Product Details
| Condition | New | Type | Wheel Tractor | |
| By wheel | 4WD | Usage | Farm Tractor | |
| Drive Type | Gear Drive | Power(W) | 18.3 | |
| Certificate | Other, ISO9001:2008 | Brand Name | LUZHONG | |
| Model Number | LZ254 | Place of Origin | Shandong, China | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
4WD wheel mini farm tractor1.Farm tractor factory
2.4 cylinder diesel engine
3.High pressure device
4.Fast delivery
Wheel Tractor Type and 4WD By Wheel Mini Farm Tractor
ISO9001 wheel tractor type mini farm tractor for sale
1)4 cylinder Chinese diesel engine (WC4105, LR4108)
2)high pressure device
3)dual speed PTO (540/1000RPM).
Characteristics:
1- Luzhong mini farm tractor 40hp, 2wd or 4wd, hydraulic steering, dual stage clutch, 3 point linkage, hydraulic suspension
2- Famous brand: Luzhong brand with long history and good reputation
3- Top quality: successfully passed ISO 9001 international quality certification system and China 3C quality system
4- Famous brand engines: strong power, low oil consumption, easy starting, and good economic performance
5- High adaptability: matches all kinds of agricultural implements
6- Diverse gear combinations: shuttle shift
7- Comfortable operation: full hydraulic system
"LZ254 4WD Mini Wheel Farming Tractor" Specifications
Model | LZ254 | ||
Type | 4WD Wheeled Type | ||
(mm)Dimensions of Tractor | Length (to front ballast) | 3030 | |
Width | 1470 | ||
Height (to the exhaust vent) | 1900 | ||
Tread | Front Wheel | 1215 Fixed or 1150~1215 Adjusted | |
Rear Wheel | 1300 Fixed or 1300~1350 Adjusted | ||
Axle Base | 1710 | ||
Min.Ground Clearance | 347.5 | ||
Structure weight (kg) | 1130 | ||
Ballast weight | Front ballast | 56 | |
(kg) | Rear ballast | 112 | |
Rated traction force (kg) | 551 | ||
Engine | Model | 385 | |
Type | Vertical,3-Cylinder,Water Cooled and 4-stroke | ||
Rated Power(kw) | 18.3 | ||
Rated speed (r/min) | 2400 | ||
Fuel | Diesel | ||
Tyre | Front Wheel | 6.00-14 | |
Rear Wheel | 9.5-24 | ||
Clutch | Dual-stage clutch | ||
Steering | power steering | ||
Transmission Type | 8+2 or 8+8 with shuttle gearshift or 16+4 with creeper shift | ||
Suspension Type | 3-point links | ||
PTO | Type and Rev | Semi-independent Type 540/1000 | |
Spline Size | F35 Rectangle Spline with 6 teeth | ||
"4WD Mini Farm Tractor" Samples
Weifang Huahai Industrial & Trade Co.,Ltd. mainly produces tractors, trailers and other farm implements. We offer products with high quality and good service to our clients. We produce over 5000 sets of tractors and farm implements every year.
Our trade amount is over USD58,000,000 per year. Our products have been exported to Asia,Middle East, Europe and Africa,South American, such as the Netherlands, Spain, Hungary,Chile,Brazil, Bulgaria, Albania, Australia,Malaysia, Iran and Egypt ect.
We would like to sincerely cooperate with customers and business partners all over the world. All kinds of cooperation methods are welcomed, including processing trade, manufacture with customers' brands and cooperative production.
"The Mini Wheel Farming Tractor Production Line"
"The Plant and Workshop "
"The Implement for Farming Tractor"
All the farm tractor will be packed with iron or steel frame, or bulk package by container, it will be packed as your requests.
Generally we produce as clients' orders, our shipment will be within 15day for 1 set, 25days for one 40ft container.
We're a manufacturer specialize in product various of mini farming tractors for 15 years, and have rich experience in product and export tractors.
- Color
Any color can be acceptable (Red,Blue,Green or as your demand).
- Warranty time and the Spare Parts
1. We supply 2 years long warranty time.
2.The Easy-damage parts, we will send you together with the tractor for free. And in warranty period, if the spare part is not work because of the quality, we will send you new parts for free.
3. We will send you the tool Box For free.
Help and Support Centre - Frequently Asked Questions
Q. I'm a complete tractor novice, never driven one in my life - can you help me?
A. Absolutely! Your new tractor comes with a training DVD and instruction manual. If you still need assistance, we're only a phone call away - we're here to help.
Q: Why are HuaxiaTractors such awesome value for money?
A: Huaxia Tractors are awesome value because we are manufacturer. We have no commercial lease to pay. Tractors and implements are stored in a rural shed, so we pass the savings directly on to you.
Q: Do implements require any assembly?
A: Yes. Most implements have some assembly required, they're typically partially assembled for transportation. Tightening of all bolts is required.
Q: What lubrication do implements require?
A: Unless otherwise stated, all implements with gearboxes, such as slashers, post hole borers and rotary tillers, are shipped dry and require the addition of gear oil.
Q: Is the three point linkage limited to just two positions? (Up or down).
A: No. The three point linkage can be stopped at any position.
Q: What type of three-point linkage does the tractor have?
A: The tractor has a Category 1 three-point linkage
Q: How much weight can the three point linkage lift?
A: This depends on which model tractor you purchase. Please review the specifications page.
Q: How much fuel does the tractor use?
A: Approximately 5 - 7 litres per hour, depending on engine capacity, speed, load, etc.
Please review the specifications page for more information.
Q: What speed and power does the PTO deliver?
A: The PTO has dual speeds: 540 / 1000 RPM.
Q: What type of brakes does the tractor have?
A: The Fumetsu has Non-Hydraulic Drum Brakes on the rear wheels.
Thanks for your visit and interest on our website, and hope our mini wheel farm tractor can be suitable for your usage, warmly welcome to inquiry for the farm tractor with details.Our team will try best offer you the configuration and quotation soonest.
Attn.: Frank Wang
Skype: frankwang09211
Mobile: 0086-13695363630
