Multifunction Machine Ipl rf Elight Vacuum Therapy Machine

International standard Aluminum Box and carton

Specifications

multifunction machine

ipl+elight+rf+cavitation+ndyag laser 5 in 1

Multifunctional machine—combine ipl. rf. E-light, cavitation, ndyag laser technology into
one machine, so that you could get 5 machines’ function from this one machine,

save your cost utmostly but make profit easily. 14.10.28
Huamei newly developed multi-functional machine with innovations:
combine rf /ipl,el-light and cavitation,vacuum technology togethr in one mahcinie.

1. combine rf /ipl,el-light and cavitation,vacuum and laser technology togethr in one mahcinie.
2. Big color touch LCD with USB software, carry out long distance upgrade operation
3. multi-head for your choice
4. strong discernment, that mean when you insert rf handle, then the machine will show rf operation window, as well as elight, ipl,cavitatin head.
5. make you get 5 different machines from one machine.
6. water filtering system to make machine water clean

1. Parameters

2. Light source	Intense pulsed Light
   Spectrum range	420/530/560/590/640/690/750nm-1200nm
   IPL energy density	10-50J/cm2
   Pulse method	Intense pulsed technology (adjustable)
   Pulse sequence	1-5pulse
   Pulse intermission	5-60ms
   Pulse width	2-15ms
   Repeat frequence	0.3-1Hz
   Deliver system	Sapphire Coupling
   E-light Spot size	12*45mm,12*40mm
   IPL Spot size	8*40mm, 15*35mm 15*50mm
   RF output level	8
   RF energy level	0-100
   Cooling temperature	-4~4°c
   Operation Interface	8.4 inch touch screen
   Cavtitation handles	Vacuum, 40Khz Cavitation and 1Mhz Cavitation handle
   Nd Yag Laser	Treatment Tattoo Removal, Wavelength: 1064nm/532nm (1064nm for skin rejuvenation optional)

   Application of multifunction beauty machine

 1. skin tightening: skin lifting, improve flexibiligy and tone of skin

 2. skin rejuvenation: remove wrinkles, pigments, freckles, vascular lesions(telangiectasis) , skin whitening, shrink large hair pores.

 3. hair removal : all kinds of skin and color

 4. acne removal: improve the situation of oily skin, kill acne bacilli.

 5. body shapping, slimming, weight loss etc.

 6. treatment Tattoo Removal

After sales service of multifunction beauty machine:

We have one year warranty, and lifetime maintenance.

Within one year, if there is some accessory going wrong, we will send you the accessory at once, free of charge.

1. Within one month, if the machine is of any big fails, we will send you a new machine.

2. Within one year, if you send back the equipment for repair, we will be responsible for the repair, including the changes of accessories; both of them are free of charge.

3. After two years, we offer to repair the machine, but we quire for the cost of the changed parts, not for manual cost.

4. No responsibility for man-made destroy.

5. If the buyer has any questions from our technical department, we can supply on-line service.
