Hot-selling 8.4" TFT Portable Veterinary Patient Monitor With CE

Features:

• 8.4” color TFT display
• Unique digital SPO technology with excellent measurement and interference-free
• Audible and visual alarms with adjustable alarm range
• Anti electrosurgical interference and defibrillation
• Can be connected with LAN to work with central monitoring system
• Powerful data management and storage capacity
• Suitable for vet use

Standard configuration:

• ECG, NIBP, SPO2, PR, Built-in rechargeable battery ,Thermal printer

Optional:

• RESP, TEMP, 2-TEMP, 2-IBP, ETCO2,

Technical Specifications:

ECG:

• Lead Mode: 5 Leads (R, L, F, N, C or RA, LA, LL, RL, V)
• Lead selection: I, II, III, avR, avL, avF, V
• Waveform: 2 ch
• Gain: 2.5mm/mV, 5.0mm/mV, 10mm/mV, 20mm/mV
• HR and Alarm Range:
  Adult: 15 ~ 300 bpm
  Neo/Ped: 15 ~ 350 bpm
  Accuracy: ±1% or ±1bpm, which great
  Resolution: 1 bpm
  Sensitivity: >200uV P-P
• Differential Input Impedance: >5MΩ
• CMRR:
  Monitor: >105dB
  Operation: >105dB
  Diagnosis: >85dB
• Electrode offset potential: 300mV
• Leakage Current: <10uA
• Baseline Recovery: <3s after Defi.
• ECG Signal Range: 8mV(Vp-p)
• Calibration Signal: 1mV (Vp-p), 5% Accuracy
• ST Segment measure and alarm: -2.0 ~ +2.0 mV

NIBP:

• Method: Oscillometry
• Mode: Manual, Auto, STAT
• Measuring Interval in AUTO Mode: 1, 2, 3, 4, 5, 10, 15, 30, 60, 90Min
• Measuring Period in STAT Mode: 5 Min
• Pulse Rate Range: 40 ~ 240 bpm
• Alarm Type: SYS, DIA, MEAN
• Measuring and alarm Range
  Adult Mode:
  SYS: 40 ~ 270 mmHg
  DIA: 10 ~ 215 mmHg
  MEAN: 20 ~ 235 mmHg
  Pediatric Mode
  SYS: 40 ~ 200 mmHg
  DIA: 10 ~ 150 mmHg
  MEAN: 20 ~ 165 mmHg
  Neonatal Mode
  SYS: 40 ~ 135 mmHg
  DIA: 10 ~ 100 mmHg
  MEAN: 20 ~ 110 mmHg
  Resolution: 1mmHg
• Over-pressure protection: YES

SPO2:

• Measuring Range: 0 ~ 100%
• Alarm Range: 0 ~ 100%
• Resolution: 1%
• Accuracy:
  70% ~ 100%: 2 %
  0% ~ 69%: unspecified
• Actualization interval: About 1Sec.
• Alarm Delay: 10 Sec.
• Pulse Rate
  Measuring and Alarm Range: 0~254bpm
  Resolution: 1bpm
  Accuracy: 2bpm
  Alarm Delay: 10 Sec.
