Infusion Pump Supplier in Hospital ICU CCU Room Obstetrics Clinic Community IP-50C

Infusion Pump

Features:

• Compatible with  IV sets of any Brand with high accuracy
• Automatic calibration for IV sets of any Brand
• Three working modes: Drop counting control,Rate control  and time control mode
• 8 Hours internal battery life in high capacity
• Has a unique color LCD and an internal battery with a high capability.
• Switch between ml/h and drops/min freely
• Three levels of alarm volume: high, medium and low
• Three levels of Occlusion pressure: high, medium and low
• KVO function: When finish the total volume of an infusion,   the pump will alarm and enter KVO state.

 Specifications:

• Controls: Drop counting and adjusting the delivery rate automatically
• Pump Type: Peristaltic finger
• Applicable IV Sets: Compatible with IV sets of any standard(including lucifugal IV sets)
• Accuracy: ≤25drop/min:±2%, >25drop/min:±3% (With the drop counting control mode)
  ±5% (With the rate control mode after the correct calibration)
• Delivery Rate Range: 1~400drop/min(1drop/min step)1.0ml/h~1200ml/h (1.0ml/h~99.9ml/h, 0.1ml/h step; >99.9ml/h, 1ml/h step)
• Delivery Time Range: 1min~1999min (1 min step)
• Volume Limit Range: 0~9999ml (1 ml step)
• Total Volume Range: 1~9999ml (1 ml step)
• Rapid injection: 600ml/h
• KVO Rate: 600ml/h
  KVO Rate: W hen the delivery rate≤10ml/h, KVO is 1 ml/h . O therwise KVO is 3ml/h.
• Alarms: Air-in-line, Infusion complete when limited volume has been set, Empty container, Occlusion, Door is open, waiting time Over, No drop been detected, Operational errors, Low battery, other device failures.
• Power Supply: AC power supply: AC 100 to 240V±10%,50/60Hz;
  Internal LI Battery: 11.1V, 2000mAh. 8 Hours of continuous operation on a new fully charged battery with the rate of 20 drops/min.
• Power Consumption: ≤25VA
• Safety level: ClassⅠ, Type BF
• Dimensions: 130mm(L)× 200mm(W) × 230mm(H)
• Net Weight: Approximately. 2.5kg
• Operating Conditions: Ambient temperature: 5 to 40℃Relative humidity: 20 to 90%
• Storage Conditions: Ambient temperature: -10 to 55℃Relative humidity: 10 to 90%
• Accessories: AC power line, Operational manual
