FDA Approved CO2 Fractional Laser Chloasma Removal Machine Medical CE ISO13485 0.1-2.6mm

Application

1. Remove acne, acne scar, scar and so on;
2. Dispel wrinkle around the eyes, crow' s-feet, and wrinkle formed by lack of water;
3. Effectively reduce the wrinkle on the face, forehead, the joints and striae gravidarum;
4. Dispel freckle, nevus zygomaticus and other spots formed by hyperchromic pathological changes;
5. Tighten skin and lift face;
6. Remove striae gravidarum and other deep scars.

Special Features

1. US-imported RF-CO2 laser generator, high quality excellent performance;
2. Excellent treatment results, perfect skin recovery in short time after treatment;
3. Humanized operation system and 8’ ’ color touch screen display;
4. Portable & smart design, easy for move and daily maintenance;
5. Smaller focal spot, stronger penetration and powerful output energy;
6. Best cost performance, designed for salons and clinics use;
7. Medical CE approval, ISO13485: 2003 and ISO9001: 2008.

Technical Parameter

Electrical Requirements

AC 110V± 10%  60Hz
AC 220V± 10%  50Hz

Beam Delivery

6 joint arm

Wavelength

10600nm

Cooling

Air cooling

1. Fractional resurfacing is a new laser treatment modality that creates numerous microscopic thermal injury zones of controlled width, depth,and density that are surrounded by a reservoir of spared epidermal and dermal tissue,allowing for rapid repair of laser-induced thermal injury. This unique modality, if implemented with proper laser- delivery systems, enables high-energy treatments while minimizing risks.
   2.This machine use the RF Tube manufacturerd by Coherent America,the frequency can reach more than5000HZ,the high speed can work more efficiecnt and effectively,it is very good for the ultra pulse incision for the precise surgey,no blood,the treatment area is very clear,andless down time.

2.


Aiming wavelength

635nm

Output mode

Continuous, super pulse, fractional

Focal Spot Diameter

0.2mm

Operating mode

Continuous, operation with, intermittent loading

Power of Aiming Beam

≤ 5mw

Whether Preview or not

Yes

Pulse Interval

1ms-5000ms, every stepping 1ms

Times of scanning

1th-20 th, every stepping 1th

Pulse Width

0.1ms-10ms, every stepping 0.1ms

Scanning Mode

Disorder emitting, to one side as the base emitting in order, emitting by maximum distance

Output Power

30W RF Metal tube from USA

Output Pattern

Beeline, triangle, right square, rectangle, hexagon, rotundity, ellipse and so on

Spots Interval

0.1mm-2.6mm, every stepping 0.1mm

Pattern Size

Diagonal length from 0.1mm to 20mm is adjustable at random
