Portable Hospital Trolley Ultrasound Machine

Electronic Micro-convex Array Transducer

5.0/6.5/8.5MHz

2.5/3.5/5.0MHz

6.5/7.5/9.0MHz

Electronic Convex Array Transducer

2.5/3.5/5.0MHz

Electronic Linear Array Transducer

6.5/7.5/9.0/10.0MHz

Electronic Endorectal Array Transducer

5.0/6.5/7.5MHz

Electronic Transvaginal Array Transducer

5.0/6.5/7.5/9.0MHz

5.0/6.5/7.5/8.0MHz

Video Printer

Laser Printer

Mobile Trolley

Flash Stick

Needle-guided Biopsy

Footswitch

General

Imaging mode

B, B+B, 4B, B+M, M

Gray scales

256

Display

10 inches non-interlaced SVGA

Probe connector

2 standard

Beam-forming

Digital Beam-forming
Dynamic Receiving Aperture
Dynamic Frequency Scanning
Dynamic Receive-focusing
Dynamic Filtering

Scanning angle

From 30 to 120 degree (depending on probes)

Scanning depth (mm)

From 40 to 250 (depending on probes)

      Imaging

    Processing

Pre-processing:
Pre-settings, Dynamic range, Edge enhancement, Frame correlation
Line correlation, 6-segment TGC adjustment, 4-focus adjustment

Post-processing:
Gray transform, Gamma correctin, Rejection, Left-right reverse
Up-down reverse, Polarity reverse
Min. 11 levels zoom, Partial zoom, Real-time histogram

  Measurement

           &

     Calculation

B-mode:

Distance, circumference/perimeter, area, volume, angle, hip joint, stenosis ratio

M-mode:

Distance, time, velocity, EF slope, heart rate
Software packages: Abdomen, gynecology, obstetrics, urology, small parts, cardiology

    Software

    packages

Abdomen, gynecology, obstetrics, urology, small parts, cardiology
