2KW TV Transmitter

2KW DVB-T Transmitter VHF/UHF

Features:
All solid-state digital TV transmitter, bandwidth is 6-8MHZ.
Pre-distortion correction, dual-exciters switch automatically.
High Linearity LDMOS Power Amplifier, high-gain power amplifier module, parallel switching power supply, it is a high-efficiency transmitter.
Telemetry and remote control by computer, web-based interface and software.
Good man-machine interface, full automatic switch the machine with one key.
Multi protection (over voltage, over current, overheating, large standing-wave ratio ...)high reliability, 24 hours continuous works.

Technical Specifications:
1. Working frequency: VHF/UHF
2. Channel bandwidth: 8MHz
3. Output power: 2KW
4. Output impedance: 50Ω
5. Output interface: Φ40
6. Output load return loss: Normal operation: -32dB
Allowed operation: -20dB
7. Power input level: 0dBm
8. Amplifier input impedance: 50Ω
9. Amplifier input interface: L16
10.Useless transmission: ≤-60dB
11.Band fluctuations: ±0.5dB
12.Band shoulder: better than 36dB
13.MER: better than 30dB
14.Size: 1840mm×1160mm×870mm
15.Weight: 500KG
