Home > Products > ERW Steel Pipe > API 5L Gr B ERW welded pipe (4'' X 5.74MM ERW pipe)
API 5L Gr B ERW welded pipe (4'' X 5.74MM ERW pipe)
- Tianjin
- T/T
You May Like
Product Details
| Thickness | 2.5, 20 | Section Shape | Round | |
| Outer Diameter | 33 - 720 mm, 33~114mm | Place of Origin | Hebei, China | |
| Secondary Or Not | Non-secondary | Application | Fluid Pipe | |
| Certification | Other, ASTM A53 | |||
| Surface Treatment | Other, black painting 3PE varnish | Special Pipe | API Pipe | |
| Alloy Or Not | Non-alloy |
Product Description
Specifications
API 5L PSL1 GrB 4'' STD ERW welded steel pipe1.DN:114 mm WT:5.74 mm
2.Length:12 m
3.Packing: bundle
Longitudinally seam ERW Welded Steel Pipe
1. Outside diameter: 33-720mm Wall thickness: 3-20mm
2. Length: 5.8M, 6M, 11.8M, 12M or according to customers requirements.
3. Material: Q195, Q215, Q235, Q345B, Q345C, 16Mn, 20# ,
L175, L245, L290, L360, L390, L415, L450, L485;
S235JR, S345JR, S355JR; CT2KP-2, CT3KP-3
ST33, ST42, ST45, ST52,
A53 /A106 Gr B,,
X42, X52, X56, X60, X65, X70 .
4. Standard and application:
a). API 5L PSL1 b). ASTM A53 c). ASTM A106 d). ASTM A283 e). ASTM A210
f). GB/T9711.1 1 g). GB/T3091-200 h). BS 1387 i). DIN1626 j). GSOT-535
5. Payment terms: 30%T/T in advance, the balance of 70% will be paid by T/T or L/C.
6. Delivery time: according to the order quantity.
7. Mechanical Property:
Steel Grade | Yield Strength | Tensile Strength | Elongation |
Mpa min | Mpa min | Af % min | |
L175/A25 | 175(25400) | 310(45000) | C |
L175P/A25P | 175(25401) | 310(45001) | C |
L210/A | 210(30500) | 335(48600) | C |
L245/B | 245(35500) | 415(60200) | C |
L245R/BR | 245(35501) | 415(60201) | C |
L290/X42 | 290(42100) | 415(60202) | C |
L290R/X42R | 290(42101) | 415(60203) | C |
L320/X46 | 320(46400) | 435(63100) | C |
L360/X52 | 360(52200) | 460(66700) | C |
L390/X56 | 390(56600) | 490(71100) | C |
L415/X60 | 415(60200) | 520(75400) | C |
L450/X65 | 450(65300) | 535(77600) | C |
L485/X70 | 485(70300) | 570(82700) | C |
Remarks:
Hebei shenzhou steel pipe manufacturing Co., Ltd is a professional manufacturer of ERW, SSAW steel pipe , USD 580million total asset, 9 production lines
