5kw Grid Tie Solar System on the Grid

FOB Price

US$ 1,000 - 6,000 / Set

1 Set(Min. Order)

Port guangzhou
Payment TermsCredit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Guangdong, China	Brand Name	rittalups
Model Number	2kw-6kw	Output Power	1 - 200KW
Output Type	Single	Weight	25kgs
Input Voltage	110v/120v	Output Voltage	220v/230v
Type	DC/AC Inverters	Output Frequency	47-55hz
Output Current	12A

Product Description

Name: 5kw grid tie solar system on the grid

Detailed Product Description

1. protections: protection against high voltage and low voltage protections, overload protection, battery reverse polarity ,ect.

2. Strong ability of resisting concussion, can load all kinds of electric apparatus and industry equipments, such as air-conditioner , refrigerator , TV sets, fans, washing machine, fill water electric motor , Rolling gate , ect

Data:

Model		T-1500	T-2000	T-3000	T-5000
Nominal input voltage	MPPT1	380V DC	380V DC	380V DC	380V DC
	MPPT2			380V DC	380V DC
Max input voltage	MPPT1	600V DC	600V DC	600V DC	600V DC
	MPPT2			600V DC	600V DC
MPPT operating Voltage range		From 60 V dc to 580 V dc
MPPT efficiency		>99%
Array configuration		1	1	2	2
Max. operating current	MPPT1	12A	15A	18A	20A
	MPPT2			18A	20A
Max. short circuit current	MPPT1	14A	18A	21A	24A
	MPPT2			21A	24A
input power range	MPPT1	30W-1600W	30W-2300W	30W-3000W	30W-4300W
	MPPT2			30W-3000W	30W-4300W
Max. input power		1700W	2300W	MPPT1+MPPT2≤4KW	MPPT1+MPPT2≤5.6KW
Max. output power		1600W	2100W	3600W	5200W
Grid voltage maximum range		From 205 to 264Vac
Nominal grid voltage		230Vac
Nominal grid frequency		50 Hz
Nominal output current		7A	9A	16A		23A
Maximum efficiency		>97%
Internal consumption during stand-by		<3W
Operating ambient temperature		From-25°C to +60°C (from-13°F to 122°F)
Enclosure protection level		IP22
Audible Noise		<10dB
Dimensions (H x W x D):		388145210mm		473280386mm		473280431mm
Weight		15	15	15		15
