2kva off Grid Solar Inverter With Charger

FOB Price

US$ 159 - 689 / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Name:2kva off grid solar inverter with charger

Features:

MODEL		1Kva	2Kva	3Kva	4Kva	5Kva
Default Battery System Voltage		12VDC	24VDC	24VDC	48VDC	48VDC
INVERTER OUTPUT	Reted Power	1000VA/ 800W	2000VA/ 1600W	3000VA/ 2400W	4000VA/ 3200W	5000VA/ 4000W
	Surge Power	2000VA	4000VA	6000VA	8000VA	10000VA
	Waveform	Pure sine wave
	AC Voltage Regulation (Batt.Mode)	230VAC±5%
	Inverter Efficiency (Peak)	90%	93%
	Transfer Time	10ms(For Personal Computers) 20ms(For Home Appliances)
AC INPUT	Voltage	230VAC
	Selectable Voltage Range	170~280VAC(For Personal Computers) 90~280VAC(For Home Appliances)
	Frequency Range	50Hz/60Hz (Auto sensing)
BATTERY	Nominal voltage	12VDC	24VDC		48VDC
	Floating Charge Voltage	13.5VDC	27VDC		54VDC
	Overcharge Protection	15VDC	30VDC		60VDC
SOLAR CHARGER & AC CHARGER	Max PV Array Power	400W	800W/1600W		3200W
	Maximum PV Array Open Circuit Voltage	30VDC	60VDC		145VDC
	Standby Power Consumption	1W	2W		2W
	Maximum Solar Charge Current	25A	25A/60A		60A
	Maximum AC Charge Current	10A or 20A	20A or 30A		60A
	Maximum Charge Current	45A	55A/90A		120A
MECHANICAL SPECIFICATIONS	Dimension,WxHxD(mm)	240×316×95	272×355×100		297.5×468×125
	Net Weight(kg)	5	6.4	6.9	9.8
OTHER	Humidity	5% to 95% Relativ Humidity (Non-condensing)
	Operating Temperature	0℃-55℃
	Storage Temperature	-15℃-60℃
	Loading (20GP/40GP/40HQ)	380PCS/760PCS/920PCS
