Product Details
| Brand Name | OEM | Model Number | WH-SP008 | |
| Place of Origin | Zhejiang, China |
Product Description
1x8 1 in 8 out 5V 1A Support 3840*2160p 3D video splitter hdmi converter
| Model: WH-SP008 | ||
| Item: 4K ULTRA HD 1X8 HDMI Splitter 1 in 8 out |
Product Description
| Feature |
| One HDMI input signal split to eight HDMI sink devices | ||
| Connect one cable from HDMI source devices into HDMI Splitter input. | ||
| Connect one cable from each display(monitor or projector) HDMI Splitter outputs. | ||
| Connect 5V power supply to the HDMI 1X8 Splitter. | ||
| Support 3D | ||
| Support deep color 30bit, 36bit | ||
| Support Blue-Ray 24/50/60fs/HD-DVD/xvYCC | ||
| Digital audio format, as DTS-HD/Dolby-trueHD/LPCM7.1/DTS/Dolby-AC3/DSD | ||
| Support signal retiming | ||
Support input up to 5metres AWG26 HDMI standard cable length, output up to 10metres AWG26 cable length | ||
| No loss of quality | ||
| Installs in minutes | ||
| Need DC5V/1A power supply |
| Specification |
| HDMI resolution(Max) | 1080p@120Hz, 4Kx2K@30Hz | |
| Support video color format | 24bit,30bit,36bit deep color | |
| Support audio format | DTS-HD/Dolby-trueHD/LPCM7.1/DTS/Dolby-AC3/DSD | |
| Max bandwidth | 340MHz | |
| Max baud rate | 10.2Gbps | |
| Input/Output TMDS signal | 0.5~1.5Volts p-p | |
| Input/Output DDC signal | 5Volts p-p | |
| Input cable distance | ≤15m AWG26 HDMI standard cable | |
| Output cable distance | ≤25m AWG26 HDMI standard cable | |
| Max working current | 1 A | |
| Power adapter format | Input: AC (50HZ, 60HZ) 100V-240V; Output: DC5V/2A | |
| Operating Temperature Range | -15℃ to +55℃ | |
| Operating Humidity Range | 5 to 90%RH (No Condensation) | |
| Dimension (L x W x H) | 280*158*25mm | |
| Weight | 536g | |
| Picture |
