Steel Elbow Beveling Machine With Two Heads
- Tianjin
You May Like
-
High Speed Elbow Beveling Machine With 2 Heads
-
Steel Elbow Beveling Machine With Two Heads,high Speed and Quality
-
Steel Elbow Pipe Beveling Machine With 2 Heads;beveling Machine for Elbow
-
Steel Elbow Pipe Beveling Machine With 2 Heads;beveling Machine for Elbow Made in China
-
Steel Elbow Pipe Beveling Machine With 2 Heads
-
2 Heads;beveling Machine for Elbow Made in China
Product Details
| Place of Origin | Hubei, China | Brand Name | Unipand | |
| Model Number | UNI-YQ | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
1) Turning diameter range widely2) Self-defined pipe center
3) Easy operation
4)Feeding turn volume:0.25mm
The machine adopts standard power unit to reform the specialized power control box with stronger turning capability and wiping action for feeding in radial direction parts; tightening adopt manual tightening centering device or adopts the main engine of power control box to make left and right regulation manually as well as V-shaped clamping head to regulate up and down for the alignment of parts .pipe ending cutting can adopt angle tool carrier to feed automatically for processing. While pipes have the thickness of less than 12mm. also can adopt manually shifting main unit for turning with molding tool.
Major technology parameters
Parameter/model | YQ-89 | YQ-168 | YQ-325 | YQ-630 | YQ-820 | YQ-1020 | YQ-1800 |
Turning diameter(mm) | 21-89 | 89-168 | 168-325 | 325-630 | 630-820 | 820-1020 | 1020-1800 |
Revolution of cutter head(rpm) | 600 | 350 | 200 | 150 | 100 | 80 | 40 |
Feeding turn volume(mm/r) | 0.25 | 0.25 | 0.25 | 0.25 | 0.25 | 0.25 | 0.25 |
Remarks : 1, the data is for reference only
2, products can be customized according to requirement .
