Home > Products > TIMER SWITCH > Digital Time Switch
Digital Time Switch
- Ningbo or Shanghai
- Credit Card PayPal
You May Like
Product Details
| Place of Origin | Zhejiang, China | Brand Name | sinotimer | |
| Model Number | TM-618 | Max. Current | 16A | |
| Max. Voltage | 250VAC |
Product Description
Specifications
Digital Time Switch / Automatic Microcomputer Programmable Weekly Clock Timer SwitchDC 5V 12V 24V. AC 110V 220V 230V 240V
TM-618 Programmable Automatic Digital Time Switch
The timer can open or close kinds of electrical apparatus and power automatically according to preset time, the items can be streetlight, neon light (sign), billboard, electrical appliances, broadcast equipments etc., The timer is within rechargeable battery in 1.2V/40Ma, high-accuracy CMOS chip, strongly anti-jamming, easy to use.
• Daily or weekly programmable timer
• LCD time display
• LED indication ON
• Manual ON/AUTO/OFF
• Lithium-ion battery , 2 years reserve
Real Timer
Program setting
Step | Electronic Timer | |
| Key | Programming |
1 | Press Timer | Setting 1 ON time (display 1 on) |
2 | Press H+/M+ | Setting hours and minutes |
3 | Press D+ | Select same everyday, different everyday, MO-FR, MO-SA, SA-SU, MO WE FR, TU TH SA, MO-WE, TH-SA.(If same everyday, no need to press this key) |
4 | Press Timer | Setting 1 off time (display 1 off) |
5 | Press H+/M+ | Setting hours and minutes turn off time |
6 | Press D+ | If you want same set in every day, you need not press this key |
7 | Repeat step 2~6 | Set 2~16 ON/OFF time |
8 | Press C/R | End |
Electronic Timer Technical Data:
• Supply Voltage: 12VDC/AC,24VDC/AC,120VAC,240VAC
• Frequency: 45-60Hz for VAC models
• Own Consumption: Approx. 4.5VA
• Switching Command: 1 minute
• 24-Hour / 12-Hour Format, by default upon ordering
• Admissible ambient temperature: -10 C to 55 C
• Square housing & slide bracket available as option
• Form C output, NO, NC, Common, ¼ Quick Connect
• Contact rating:Resistive 16A, Inductive 8A, Motor 1/2HP
PLEASE SPECIFY DESIRED VOLTAGE YOU NEED FOR YOUR APPLICATION.... 12VDC/AC, 24VDC/AC, 120VAC, 240VAC
