Home > Products > Ductile iron pipe > Water Project!!! ISO2531 Ductile Iron Pipe K8/K9 Manufacture
Water Project!!! ISO2531 Ductile Iron Pipe K8/K9 Manufacture
US$ 685 - 865
/ Ton
2 Tons(Min. Order)
- Tianjin xin'gang
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Shanxi, China | Brand Name | Xinxing | |
| Model Number | K7 K8 K9 | Length | 6Meters | |
| Standard | EN598 | Application | water project | |
| Diameter | DN80-DN1200 | Shape | Round | |
| Hardness | 230 | Pipe Wall Thickness | 1-150mm | |
| Pull Strength | 420 | Material | Ductile Iron | |
| Type | Other, iron pipe |
Product Description
Specifications
water project!!! ISO2531 ductile iron pipe K8/K9 manufacture1:High quality
2:Competitive price
3:Best service
water project!!! ISO2531 ductile iron pipe K8/K9 manufacture
1.Products Description
| Item | ductile iron pipe |
| Material | Q235A,Q235b,0Cr13,K8,K9,K10,Q345,L245,L290,X42,X46,X70,X80 X95 |
| Surface | Black painted,PE coated,HDPE,Varnished,Galvanized ,anti-rush oiled,etc |
| Length | 6m,5.8m,11.8m,12m, or as required |
| Size | thickness:1mm-150mm ,diameter :DN80-DN1200 |
| PaymentTerms | T/T,L/C,western union |
| Price terms | FOB,CIF,CFR,EXW |
| Package | Standard export package or as required. |
| Application | Low temperature steel pipe applies to petrochemical,chemical industry used.Low temperature steel pipe can be made according to the customers requirements. |
| Contact | If you have any question,please feel free to contact me. |
2.Some Specification:
| DN(mm) | DE(mm) | Thickness of Wall (mm) | Weight of Socket(kg) | Total Weight(kg) | ||||
| K8 | K9 | K10 | 3.4 | K8 | K9 | K10 | ||
| 80 | 98 | 6.0 | 6.0 | 6.0 | 4.3 | 77.0 | 77.0 | 77.0 |
| 100 | 118 | 6.0 | 6.0 | 6.0 | 5.7 | 93.7 | 95.0 | 95.0 |
| 125 | 144 | 6.0 | 6.0 | 6.0 | 7.1 | 119.0 | 119.0 | 121.0 |
| 150 | 170 | 6.0 | 6.O | 6.0 | 10.3 | 138.0 | 144.0 | 144.0 |
| 200 | 222 | 6.0 | 6.3 | 6.4 | 18.9 | 183.0 | 194.0 | 194.0 |
| 300 | 326 | 6.4 | 7.2 | 8.0 | 23.7 | 290.0 | 323.0 | 357.0 |
| 350 | 378 | 6.8 | 7.7 | 8.5 | 29.5 | 359.0 | 403.0 | 441.0 |
| 400 | 429 | 7,2 | 8.1 | 9.0 | 38.3 | 433.0 | 482.0 | 532.0 |
| 450 | 480 | 7.6 | 8.6 | 9.5 | 42.8 | 515.0 | 577.0 | 632.0 |
| 500 | 532 | 8.0 | 9.0 | 10.0 | 59.3 | 600.0 | 669.0 | 736.0 |
| 600 | 635 | 8.8 | 9.9 | 11.0 | 79.1 | 791.0 | 882.0 | 971.0 |
| 700 | 738 | 9.6 | 10.8 | 12.0 | 102.6 | 1009.0 | 1123.0 | 1237.0 |
| 800 | 842 | 10.4 | 11.7 | 13.0 | 129 | 1255.0 | 1394.0 | 1537.0 |
| 900 | 945 | 11.2 | 12.6 | 14.0 | 161.3 | 1521.0 | 1690.0 | 1863.0 |
| 1000 | 1048 | 12.0 | 13.5 | 15.0 | 237.7 | 1811.0 | 2017.0 | 2221.0 |
