DSMAC Mobile Rock Crusher and Screen Plant

Specifications

DSMAC mobile rock crusher and screen plant

Founded in 1997, DSMAC Group is a mobile crusher manufacturer.we have mobile jaw crusher ,mobile impact crusher,mobile cone crusher ,Mobile VSI Crusher and Portable Crawler Crusher.

DSMAC mobile rock crusher and screen plant Application

1.Quarrying and surface mining

2.Road construction aggregates

3.Crushing contractors

4.Aggregate production

5.Primarily any mineral application that requires precision compact crushing delivered at high production rates and where mobility is at a premium.

DMP 1010 PFS Mobile Impact Crusher

Impact crusher: PF1010

Feed opening (mm): 400*1080

Screen Model: 4YK1235

Transport Dimensions Length*Width*Height (mm): 10800*2480*4170

Transport Dimensions Weight (kg): 28800

Transport Dimensions Axle weight (kg): 15900

Transport Dimensions King pin weight (kg): 11300

DMP600 Mobile Jaw Crusher

Jaw Crusher Model: PE400*600

Feed opening (mm): 400*600

Setting range (mm):40-100

Capacity (m³/h): 10-35

Feeder Model: GZT0724

Feed hopper volume (m³):3

Feeder Hopper width (mm):2200

Belt conveyor Model: B650*6

Transport Dimensions Length*Width* Height* (mm): 8600*2520*3770

Transport Dimensions Weight (kg): 15240

Transport Dimensions Axle weight (kg): 10121

Transport Dimensions King pin weight (kg): 5110

DMP 250 PFS Mobile Cone Crusher

Cone crusher: DYP250

Feed opening (mm): 240

Setting range (mm): 26-51

Screen model: According to the output size requirement

Belt conveyor model: B1000*8

Transport Dimensions Length*Width*Height (mm): 10816*2743*4160

Transport Dimensions Weight (kg): 35700

Transport Dimensions Axle weight (kg): 22900

Transport Dimensions King pin weight (kg): 12800

Payment & shipping terms

1.Price:FOB USD 5000-999999/ piece (negotiation)

2.Minimum Order Quanlit(MOQ):1 piece

3.Port:Shanghai;tianjin;qingdao

4.Packaging Details:Standard Container, Nude Packs or in Bulk.

5.Delivery Time:15-30 days

6.Payment Terms:L/C,T/T

7.Supply Ability:64 Set/Sets per Month

If you want to get the price, please send us the detailed materials information, such as the hardness of raw materials,feeding size, you required output size,capacity and other special requirement.Our engineer will choose the optimum type and our saleman will send you the resonable price.
