Conveyor Belt (B-500)

FOB Price

US$ 5,000 - 99,999 / Set

1 Set(Min. Order)

Port Tianjin Qingdao or Shanghai
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Vibrating Conveyor
Material	Stainless Steel	Material Feature	Heat Resistant
Structure	Belt Conveyor	Load Capacity	large
Place of Origin	Henan, China	Brand Name	DSMAC
Model Number	B Series Belt conveyor	Voltage	220
Power(W)	according to capacity	Dimension(LWH)	according to capacity
Certification	ISO9001	After-sales Service Provided	Engineers available to service machinery overseas

Product Description

Conveyor Belt (B-500) Application

The belt conveyor made by our company has the strongpoints like large conveying amount, simple structure, easy maintenance, high standardization degree etc. It is widely used in mining, metallurgy, coal and other industries. The belt conveyor can be used to transport bulk materials or materials in pieces. According to different transportation requirements, the transportation system can be only one belt conveyor or consisted of several conveyors, or combined with other transporting equipment. The belt conveyor can be installed horizontally or aslope to meet the needs of different transporting requirements.

Conveyor Belt (B-500)Working principle

The motor drives the driving rollers of the belt conveyor, and drives the roller through the strong belt advances. Materials are conveyed from the original place to the place where they are needed.

Conveyor Belt (B-500) technical parameter

Belt Width(mm)	Belt Length (m) / Power (KW)			Belt Speed(m/s)	Capacity(t/h)
B400	≤12/1.5	12~20/2.2~4	20~25/3.5~7.5	1.3~1.6	30~60
B500	≤12/3	12~20/4~5.5	20-30/ 5.5~7.5	1.3~1.6	40~80
B650	≤12/4	12~20/5.5	20 ~30/7.5~11	1.3~1.6	80~120
B800	≤6/4	6~15/5.5	15~30/7.5~15	1.3~1.6	120~200
B1000	≤10/5.5	10~20/7.5~11	20~40/11~12	1.3~2.0	200~320
B1200	≤10/7.5	10~20/11	20~40/15~30	1.3~2.0	320~500

Workshop

the entrance of factory
