6V200AH Gel Renewable Energy Storage Solar Battery
- Shanghai Ninibo
- T/T
You May Like
-
Deep Cycle Maintenance Free 12V 200AH Solar Battery
-
Chilwee MF Silicone Gel Battery 12V175AH/20HR For Solar System
-
Chilwee MF Silicone Gel Battery 12V200AH/20HR For Solar System
-
1000Ah Deep Cycle Lead Acid Solar Battery
-
1000Ah Deep Cycle Lead Acid Energy Storage Battery
-
12V7 BATTERY POWERED SYSTEM for Home Lighting Systems
Product Details
| Place of Origin | Zhejiang, China | Brand Name | Chilwee | |
| Model Number | 3-CNFJ-200 | Type | Other, Rechargeable battery | |
| Nominal Voltage | 6V | Size | Other, 330*180*214.5mm | |
| Nominal Capacity | 200AH/3HR |
Product Description
Chilwee CNFJ Series VRLA Gel Battery is specially designed for renewable energy storage and motive power, i.e. solar/wind energy storage, hybrid system, electric car, etc. The CNFJ Series adopts flat plate Sillicon Gel technology to ensure the batteries with long cycle life, large current discharge capability, high reliability and safety, and enviornmental-friendly.
1. Electric car
2. Hybrid system
3. Solar /Wind energy storage
4. Other DC power system
| SPECIFICATION | |||||||||
| Nominal Voltage | 6V | ||||||||
| No. of Cells | 3 Cells | ||||||||
| Rated Capacity (2h rate) | 175Ah to 1.8V/Cell @ 25℃/77℉ | ||||||||
| Nominal Weight | Approx. 36 Kg | ||||||||
| Internal Resistance | Approx. 2.6 mohm | ||||||||
| Float Voltage | 2.27V/Cell @ 25℃/77℉ | ||||||||
| Equalization Voltage | 2.37V/Cell @ 25℃/77℉ | ||||||||
| Maximum Charge Current | 50 Amperes | ||||||||
| Short Circuit Current | 3500A | ||||||||
| Operating Temperature Range | Max.: -20 to 50 ℃; Recommended: 20 to 30 ℃ | ||||||||
| Self Discharge Rate | < 3% per month | ||||||||
| Terminal Type | M8 | ||||||||
| Container Material | ABS | ||||||||
| Cycle Life, 25℃ | @80% DOD | 1000 Cycles | |||||||
| @50% DOD | 2000 Cycles | ||||||||
| @30% DOD | 4000 Cycles | ||||||||
| DISCHARGE DATA OF CONSTANT CURRENT (AMPERES, 25℃) | |||||||||
| End Voltage Per Cell | Time / Amperes, 25℃/77℉ | ||||||||
| 30 min | 1 h | 2 h | 3 h | 5 h | 8 h | 10 h | 20 h | ||
| 1.60V | 258.00 | 158.00 | 95.00 | 64.00 | 39.80 | 25.50 | 20.60 | 10.55 | |
| 1.70V | 236.00 | 148.00 | 92.50 | 62.33 | 39.00 | 25.13 | 20.40 | 10.45 | |
| 1.75V | 220.00 | 140.00 | 90.00 | 61.00 | 38.20 | 24.75 | 20.10 | 10.30 | |
| 1.80V | 202.00 | 132.00 | 87.50 | 59.67 | 37.20 | 24.25 | 20.00 | 10.20 | |
| 1.85V | 184.00 | 124.00 | 85.00 | 58.00 | 36.20 | 23.75 | 19.30 | 9.75 | |
| DISCHARGE DATA OF CONSTANT POWER (AMPERES, 25℃) | |||||||||
| End Voltage Per Cell | Time / Amperes, 25℃/77℉ | ||||||||
| 30 min | 1 h | 2 h | 3 h | 5 h | 8 h | 10 h | 20 h | ||
| 1.65V | 451.5 | 284.4 | 171 | 117.12 | 75.222 | 47.94 | 40.17 | 20.5725 | |
| 1.70V | 413 | 266.4 | 166.5 | 114.07 | 73.71 | 47.235 | 39.78 | 20.3775 | |
| 1.75V | 385 | 252 | 162 | 111.63 | 72.198 | 46.53 | 39.195 | 20.085 | |
| 1.80V | 353.5 | 237.6 | 157.5 | 109.19 | 70.308 | 45.59 | 38.415 | 19.5 | |
| 1.85V | 322 | 223.2 | 153 | 106.14 | 68.418 | 44.65 | 37.635 | 19.0125 | |
| * This data is only for customer's reference. It was taken according to lab test at ideal working condition with proper charge. It may be different from actual test result. | |||||||||
| CHARGE METHOD | |||||||||
| Type | Voltage (V/Cell) | Temperature Compensation Coefficient | Charge Current (A) | ||||||
| Cycle Application | 2.36-2.43V | -4mV/℃ | 0.1C10 - 0.25C10 | ||||||
| Float Application | 2.25-2.29V | -3mV/℃ | |||||||
Packaging & Shipping
Paper carton for per bank battery, Then stripped with plstic pallet.
7-10 Days
Chilwee products have already been distributed in all over world, and local service facilities are being deployed in each region. Chilwee is committed to provide complete services including technology training, warranty replacement service, fault analysis trouble-shooting, battery maintenance service and battery disposal service, etc.
