Home > Products > Electric Bicycle Battery > VRLA Gel Battery for Electric Scooters, 12V10Ah @2hr
VRLA Gel Battery for Electric Scooters, 12V10Ah @2hr
- Shanghai Seaport
- T/T
You May Like
-
SLA (Sealed Lead Acid) Battery for E-bike, 12V 10Ah
-
Maintanence Free Lead-acid Battery CHILWEE 6-DZM-12(12V12A@2HR)
-
Maintanence Free Lead-acid Battery CHILWEE 6-DZM-12(12V20A@2HR)
-
Maintanence Free Lead-acid Battery CHILWEE 6-DZM-27(12V27A@2HR)
-
SLA Battery 12V15A@20HR CHILWEE Brand
-
8V200A@10HR CHILWEE 4-EVF-150 VRLA Battery for Road Sweeper
Product Details
| Place of Origin | Zhejiang, China | Brand Name | Chilwee | |
| Model Number | 6-DZM-10 | Usage | Motorcycle / Scooter | |
| Voltage | Other, 12v | Sealed Type | Sealed | |
| Maintenance Type | Free | Size | (151mm±2) X (99mm±2) X (94mm±2), (100mm±2) | |
| Weight | 4.2Kgs | Nominal Capacity | 10Ah |
Product Description
Chilwee DZM series VRLA Gel Type E-Bike Battery is specially designed for motive power applications, that is electric bicycles, electric tricycles, electric motorcycles and other device require DC power source. DZM series adopts international leading technologies to ensure the batteries with features of long cycle life, large current discharge capability, high reliability and safety and environment-friendly.

1. Electric Bicycles
2. Electric Tricycles
3. Electric Scooters
4. UPS
5. Other DC power system
1. ISO9001
2. ISO14001
3. CE
4. ROHS
- Non-cadmium design, environment-friendly: Chilwee Battery has adopted internationally leading technology-container formation non-cadmium production technology, which is in the leading position in the industry. It helps to save energy 28.5%, save water 90%, and non-discharge of waste water
Super Long Voyage Ability: The discharge time of Chilwee battery is prolonged. Active additive has been added in postive plates, so as to good consistency of the formated active material. This enables the battery has high charge/discharge efficiency, and the power output is elevated. Discharge time of Chilwee battery is prolonged
Strong Motive Power: Super thin plate design is adopted to increase the area of the plates macroscopic electrochemical reaction, which enables the battery has excellent large current discharge ability. Adopting cast-weld process to reduce the battery's internal resistance, and it improves battery charging acceptance capability. Battery's charge/discharge efficiency is high.
High Durability: The Chilwee battery has excellent cycle life which can reach 600 cycles @ 80% DOD. The battery banks has good consistency. Enhanced ABS material has been adopted on battery container and lid, and the battery is well sealed to prevent leakage.
High Reliability and Safety: Improved negative material prescription and increased micropoles structure at negative helps to improve a lot on low temperature charge/discharge performance. Low water loss rate, high temperature resistance, and the pressure value of Open/Close safety valve is accurate to prevent battery bulging. Safety valve and acid filter can efficiently prevent sparks splashed into battery to ensure safe operation.
Battery Model | 6-DZM-10 |
Nominal Voltage (V) | 12V |
Open Circuit Voltage (V/Block) | 13.1-13.45V |
Number of Cells (Per Block) | 6 cells |
Rated Capacity, 2-hour rate (25°C to 1.75VPC) | 10Ah |
Rated Capacity, 3-hour rate (25°C to 1.75VPC) | 20.5Ah |
Rated Capacity, 5-hour rate (25°C to 1.8VPC) | 11.5Ah |
Rated Capacity, 20hr rate (25 Degree C, to 1.8VPC) | 13.8Ah |
Nominal Weight (kg) | Approx. 4.2Kgs |
Dimension (L x W x H, Total Height) | (151mm±2) X (99mm±2) X (94mm±2), (100mm±2) |
Container Material | Enhanced ABS |
Charge Voltage at Float Application (V) | 13.5-13.8V |
Charge Voltage at Cycle Application (V) | 14.5-14.8V |
Maximum Discharge Current (A) | 80A (5s) |
Maximum Charge Current (A) | 1.8A |
| Complete Range of DZM Series for Electric Bicycles | |||||||||
| Model No. | Nominal Voltage (V) | Capacity (Ah) | Dimension (mm) | Reference Weight (Kg) | |||||
| 2HR | 3HR | 5HR | Length | Width | Height | Total Height | |||
| 6-DZM-10 | 12V | 10Ah | 10.5Ah | 11.5Ah | 151mm±2 | 99mm±2 | 94mm±2 | 100mm±2 | 4.2Kgs |
| 6-DZM-12 | 12V | 12Ah | 12.7Ah | 13.6Ah | 151mm±2 | 99mm±2 | 97mm±2 | 101mm±2 | 4.3Kgs |
| 6-DZM-14 | 12V | 14Ah | 14.8Ah | 15.9Ah | 151mm±2 | 99mm±2 | 116mm±2 | 119mm±2 | 5.4Kgs |
| 6-DZM-16 | 12V | 16Ah | 16.9Ah | 18.2Ah | 151mm±2 | 99mm±2 | 123mm±2 | 127mm±2 | 5.8Kgs |
| 6-DZM-20 | 12V | 20Ah | 21.1Ah | 22.7Ah | 181mm±2 | 77mm±2 | 170mm±2 | 172mm±2 | 7.0Kgs |
| 6-DZM-24 | 12V | 24Ah | 25.4Ah | 27.3Ah | 166mm±2 | 175mm±2 | 126mm±2 | 126mm±2 | 9.5Kgs |
| 6-DZM-25 | 12V | 25Ah | 26.4Ah | 28.4Ah | 320mm±2 | 81mm±2 | 119mm±2 | 119mm±2 | 9Kgs |
| 6-DZM-27B | 12V | 27Ah | 28.5Ah | 30.6Ah | 166mm±2 | 175mm±2 | 126mm±2 | 126mm±2 | 9.5Kgs |
| 8-DZM-10 | 16V | 10Ah | 10.5Ah | 11.3Ah | 151mm±2 | 101mm±2 | 109mm±2 | 110mm±2 | 5.2Kgs |
| 8-DZM-14 | 16V | 14Ah | 14.8Ah | 15.9Ah | 201mm±2 | 112mm±2 | 100mm±2 | 105mm±2 | 6.9Kgs |
| 8-DZM-18 | 16V | 18Ah | 19Ah | 20.4Ah | 250mm±2 | 100mm±2 | 126mm±2 | 130mm±2 | 9Kgs |
| 8-DZM-20 | 16V | 20Ah | 21.1Ah | 22.7Ah | 250mm±2 | 100mm±2 | 129mm±2 | 132mm±2 | 9.8Kgs |
| 6-EVF-24 | 12V | 20Ah | 21.1Ah | 22.7Ah | 190mm±2 | 115mm±2 | 127mm±2 | 129mm±2 | 7.8Kgs |
| 6-EVF-32 | 12V | 30Ah | 32Ah | 35Ah | 267mm±2 | 77mm±2 | 170mm±2 | 170mm±2 | 9.8Kgs |
| 6-EVF-38 | 12V | 35Ah | 38Ah | 40Ah | 222mm±2 | 106mm±2 | 171mm±2 | 171mm±2 | 12.2Kgs |
| 6-EVF-45 | 12V | 40Ah | 45Ah | 48Ah | 226mm±2 | 120mm±2 | 175mm±2 | 175mm±2 | 13.5Kgs |
| 6-EVF-48 | 12V | 44Ah | 48Ah | 50Ah | 197mm±2 | 165mm±2 | 165mm±2 | 165mm±2 | 13.8Kgs |
