SVC Three Phases Fully Automatic Voltage Stabilizer

FOB Price

Negotiable / Piece

100 Pieces(Min. Order)

Port ningbo shanghai ETC.
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Zhejiang, China	Brand Name	kasan
Model Number	SVC	Usage	SVC
Phase	Three Phase	Current Type	AC

Product Description

Specifications

1.Servo motor control
2.Input voltage: 160-250V
3.Output voltage: 220V

Detailed Selling Lead Description

Application

SVC fully automatic voltage regulator consists of contact voltage regulator,sampling control circuit and servo motor as well.It has excellent features,such as small waveform distortion,high efficiency,high power factor,free from the effect of frequency variation of supply.It can be widely used in most situations where the voltage stabilization is required.

Specifications

Input voltage	160V~250V 70~130V
Output voltage	220±3% with 110V±3%
phase	Single phase
Frequency	50HZ/60HZ
Response time	With 1 sec, against 10% input voltage deviation
Efficiency	Better than 90%
Ambient temperature	-5°C~+40°C
Relative humidity	Less than 95%
Waveform distortion	Non-lack fidelity in waveform

Information For Packing

Model	Output Power	Measurement (cm)	Qty Packed in one CTN
SVC-500	500VA	50X46X19	4PCS
SVC-1000	1000VA	55X51X21	4PCS
SVC-1500	1500VA	58X54X22	4PCS
SVC-2000	2000VA	31X29X23	2PC
SVC-3000	3000VA	38X31X32	1PC
SVC-5000	5000VA	55X33X27	1PC
SVC-8000	8000VA	54X31X34	1PC
SVC-1000	10000VA	54X31X34	1PC

Application

Computer	Communication system	Numeric control maching tool
Test equipment	Medical equipment	Industrial robot
Lighting equipment	Auto process control equipment	Laboratory instrument
Alarm and security system	Broadcasting equipment	TV-set
X-ray equipment	Photographic processing equipment	Hi-Fi equipment
