YT-W2 Collapsible Plywood Box Machine
- shagnhai or ningbo
 - T/T L/C D/P D/A Credit Card PayPal

You May Like
Product Details
| Condition | New | Automatic Grade | Automatic | |
| Usage | Other Forming Machine | Place of Origin | Zhejiang, China | |
| Brand Name | Yutong | Model Number | YT-W2 | |
| Voltage | 380V | Power(W) | 5.5KW | |
| Dimension(L*W*H) | L=3300mm B=1200mm H=1000mm | Weight | 1500 kg | |
| Certification | EU CE Certificate, ISO9001 2008 Authentication | Warranty | One year | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
What makes us better than others
YT-W2 Collapsible plywood box machine
This Roll Forming Machine consist of sheet feeding device, roll forming main machine, hydraulic system, PLC controller.
Working Flow
sheet feeding--roll forming--automatic cutting--run out table
Main Parameter
No  | Item  | Parameter  | Note  | ||
1  | Suitable
 Material  | Type  | Pre-paint Steel Aluminum  |
  | |
Width  | 40mm-42mm  |
  | |||
Thickness  | 0.70mm—0.80mm  |
  | |||
2  | Product Specs  | Length  | Any length  | Adjustable  | |
3  | Machine
 Material  | Active shaft  | No. 45 steel tempered  |
  | |
Roller  | No. 45 steel chrome plated  | ||||
Cutting Blade  | Cr12 quenched  | ||||
4  | Power Requirement  | Type  | 380V/3PH/50HZ  |
  | |
Total  | 7.5kw  |
  | |||
Hydraulic  | 4kw  | ||||
5  | Speed  | Forming speed  | 15-18m/min  | Adjustable  | |
7  | Speed  | Product speed  | 5-10m/min  | Adjustable  | |
8  | Transmission style  | Chain, sprocket  |
  | ||
9  | Main machine structure  | Wall Panel  |
  | ||
10  | Type of Cutting  | length-set cutting  | Hydraulic cutter  | ||
11  | Control System  | Mitsubishi PLC& transducer  |
  | ||
12  | Product support  | Run out table  | |||
Detailed Picture
Nailless / Foldable / Collapsible / No-nail Plywood box machine



Rollers
moulds
safty shield
Steel Strip / Belt / Band
buttons
Nailless / Foldable / Collapsible / No-nail Plywood box
If you have any question pls let us know when you feel free, thank you!
