Home > Products > Cartridge heater > split sheath risistance cartridge heater 24V,12V
split sheath risistance cartridge heater 24V,12V
- 500 Piece / Pieces per Month
- shanghai port
You May Like
Product Details
| Condition | New | Type | Band Heater | |
| Power Source | Electric | Brand Name | DNR | |
| Model Number | Customized | Dimension(L*W*H) | Custom Size | |
| Weight | Final Dimension | Voltage | 220-380V | |
| Power(W) | 1w-10000w | Certification | ISO9001 | |
| Warranty | 1 Year | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
• Sheath material: stainless steel ss304/316/321
• Heating resistance wire:Cr20Ni80
• Working temperature: max 700°C
• Diameter range (mm):2.6mm-30mm
• Length range (mm):15mm-3000mm
• Diameter tolerance: metric -0.02/-0.06mm
• Length tolerance: ±1mm
• Power tolerance: +5%,-10%
• Rated voltage (110-220):max1.27 times
• Insulation resistance: min5Ω
• With(and voltage:1500v/min)
• Designed life:3000 hours
• Power density:
1) -heating in mold: 45w/cm2(max)
2) -heating in water: 67w/cm2(max)
3) -heating in static air: 10w/cm2(max)
4) -heating in flowing air: 18w/cm2(max)
5) Wire lead: fiberglass
