Home > Products > Juice Drink Filling Line > Juice Washing, Filling, Capping Machine
Juice Washing, Filling, Capping Machine
- 5 Set / Sets per Month
- shanghai
- T/T Credit Card
You May Like
Product Details
| Condition | New | Application | Food, Beverage | |
| Packaging Type | Bottles | Packaging Material | Wood | |
| Automatic Grade | Automatic | Driven Type | Electric | |
| Voltage | 380V/50HZ | Power | 4Kw | |
| Place of Origin | Jiangsu, China | Brand Name | Huanyu | |
| Model Number | RCGF18-18-6 | Dimension(L*W*H) | 2500*2000*2400MM | |
| Weight | 3500Kg | Certification | CE/SGS | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
1.bottled juice filling machine2.advanced PLC control
3.sus304
4.capacity:3000-28000b/h
5.CE
Juice Washing, Filling, Capping Machine
Usage of hot drinks making machine:
The series of equipmenet are used for hot filling of green tea,black tea,wulong tea and fruit juice drink.
Characteristics of hot drinks making machine :
The machine integrates washing ,filling and capping.The design is scientific and reasonable.The machine adopts block bottle-neck and block design,and also adopts rise-drop filling valve design.It satisfies hot filling technology of temperature beow 95°C,person-machine interface touch-screen,PLC,and inverter etc.It is a good equipment chose for hot drink filling machine.
Juice Washing, Filling, Capping Machine :Main Technical Parameter
Main Technical Specifications | ||||||
Model(RCGF series) | 16-12-6 | 18-18-6 | 24-24-8 | 32-32-10 | 40-40-12 | 50-50-15 |
Production(600ml)(b/h) | 4000 | 6000 | 10000 | 15000 | 20000 | 24000 |
Way of filling | Mico-negative pressure filling technology | |||||
Filling precision | precision±5mm | |||||
FeedbackConsumption | ≤8% | |||||
PolyesterBottleStandard(mm) | (Bottle dimaeter)50-92,(Height) 150-320 | |||||
Suitable cap shape | Plastic screw cap | |||||
WaterPressureOfWashing bottle(MPa) | 0.2-0.25 | |||||
WaterConsumption forWaterBottle(kg/h) | 800 | 1600 | 2500 | 3500 | 4000 | 4500 |
GasSourcePressure(MPa) | 0.4 | |||||
GasConsumption(m3/min) | / | 0.3 | 0.4 | 0.5 | 0.55 | 0.6 |
Total power(kw) | 5.88 | 6.68 | 7.68 | 9.18 | 10.18 | 11.18 |
Total weight(kg) | 2500 | 3500 | 5500 | 8000 | 10000 | 12000 |
Dimension(L*W*H)(mm) | 2300*1550*2500 | 2516*2016*2700 | 3000*2200*2800 | 3800*2800*2900 | 4550*2750*2900 | 5450*3300*2900 |
Juice Washing, Filling, Capping Machine picture
Zhangjiagang Huanyu Beverage Machinery Co.,Ltd is a professional Manufacturer of Beverage Filling Machinein China.
Main produce: Bottled Water filling machine,Juice/Tea drink filling machine,Carbonated drinks/Beer Filling machine,Pop can Filling machine,
Water treatment equipment, Bottle Blowing machine, Bottle Unscrambler ,Labeling/packing machine and so on.
More detailed information .Please feel free to contact me.
Name | Derek Liang |
Mobile phone | +86-15962348757 |
Office Tel | +86-512-58536922 |
Skype | derekmachinery |
522756388 |
