Home > Products > Juice Drink Filling Line > Orange Juice Filling 3-in-1 Machine
Orange Juice Filling 3-in-1 Machine
- shanghai port
- T/T
You May Like
Product Details
| Place of Origin | Jiangsu, China | Brand Name | HY | |
| Model Number | BRGF |
Product Description
Specifications
juice /tea filling machine,bottling machineBRGF series glass bottle juice filling machine
PLC control
capacity:1000-8000
Application:
This series machine integrates washing, filling and capping into one unit, it can be used for glass bottle juice hot-filling production line of different kinds of fruit juice, tea, etc.
The machine whole process is automatic, The advanced OMRON programmed controller (PLC) is adopted to control the machine to run automatically while a transducer is used in the bottle-entering chains to adjust speeds and coordinated with the transducer of the main machine to make the operations of moving bottle forward more steadily and reliably. The machine is an idea preferred equipment for juice beverage makers because it is convenient to operate with higher automation while every part of the machine is inspected to run with photo electricity.
This series machine optional capacity can be from 1000 BPH to 8000 BPH.
Main technical parameter
| Model | BRGF12/12/6 | BRGF18/18/6 | BRGF24/24/8 | BRGF32/32/10 |
| Productivity: (300ml)(b/h) | 3000 | 4000 | 6000 | 8000 |
| Power (kw) | 1.2 | 3.75 | 5.6 | 6.2 |
| Dimension (mm) | 1700x1100x2300 | 1830x1320x2300 | 1950x1580x2500 | 2100x1850x2500 |
| Weight (kg) | 2500 | 3500 | 4500 | 6000 |
