Home > Products > Carbonated Drink Filling Line > DCGF 32-32-8 Type Automatic Carbonated Drink Filling Machine
DCGF 32-32-8 Type Automatic Carbonated Drink Filling Machine
US$ 10,000 - 100,000
/ Set
1 Set(Min. Order)
- Shanghai Port
- T/T
You May Like
-
PET Bottle Automatic Carbonated Beverage Filling Machine (DCGF32-32-8)
-
DCGF24248 Carbonated Soft Drink Filling Line
-
DCGF 32-32-8 Type Automatic Carbonated Beverage Filling Line
-
Carbonated/Soft Drink Filling Line(Soda Water)
-
Rinser Filling and Capping Machine 3-In-1 Unit 2000-3000BPH
-
Isobaric Filling Capping Machine Monoboock
Product Details
| Condition | New | Application | Beverage | |
| Packaging Type | Bottles | Packaging Material | Other, wooden case | |
| Automatic Grade | Automatic | Driven Type | Electric | |
| Power | 6.23kw | Place of Origin | Jiangsu, China | |
| Brand Name | HUANYU | Model Number | DCGF |
Product Description
Specifications
Filling machinery1.capacity:2000-24000b/h
2.bottle:PET
3.PLC control
washing filling cappong 3-in-1
Automatic filling machine:
Usage: The automatic filling machine is used in production of polyester bottle-packing carbonated drink, such as Coca cola, Pepsi-cola, Sprite drink etc.
Characteristics: It can carry out washing bottle, filling and capping in one machine. The whole machine designing is reasonable. The appearance is beautiful and the maintenance is convenient. It adopts hanging type conveying-bottle structure to make changing bottle model more convenient, faster and more easy. The main machine adopts advanced PLC control technology. The key electric elements are adopt international famous products.
Main technical parameter:
| Model | DCGF16-12-6 | DCGF18-18-6 | DCGF24-24-8 | DCGF32-32-8 | |
| Production capacity(500ml b/h) | 2000-3000 | 3000-4000 | 4000-6000 | 6000-8000 | |
| Filling precision | <5mm(liquid level) | ||||
| Filling pressure (MPa) | <0.4 | ||||
| Gathers the fat bottle specification(mm) | bottle diameter:50-100 height:150-310mm | ||||
| suitable cap shape | Plastic screw cap | ||||
| Total power(kw) | 1.2 | 3.75 | 5.6 | 6.2 | |
| Weight(kg) | 2500 | 3500 | 4500 | 6000 | |
| Overall dimensions(mm) | 2250*1700*2300 | 2400*1960*2300 | 3010*2180*2400 | 4000*2250*2500 | |
