Home > Products > Carbonated Drink Filling Line > Soft Carbonated Drink Production Line
Soft Carbonated Drink Production Line
US$ 10,000 - 100,000
/ Set
1 Set(Min. Order)
- Shanghai Port
- T/T D/P D/A Credit Card PayPal
You May Like
-
PET Bottle Filling Machine
-
DCGF 32-32-8 Type Automatic Carbonated Drink Filling Machine
-
PET Bottle Automatic Carbonated Beverage Filling Machine (DCGF32-32-8)
-
DCGF24248 Carbonated Soft Drink Filling Line
-
DCGF 32-32-8 Type Automatic Carbonated Beverage Filling Line
-
Carbonated/Soft Drink Filling Line(Soda Water)
Product Details
| Condition | New | Application | Beverage | |
| Packaging Type | Cans, Bottles, Barrel | Packaging Material | Plastic, Glass | |
| Automatic Grade | Automatic | Driven Type | Electric | |
| Voltage | by customer's requirement | Power | 2.87kw-15kw | |
| Place of Origin | Jiangsu, China | Brand Name | HUANYU | |
| Model Number | DCGF24-24-8 | Dimension(L*W*H) | 3100*2200*2800mm | |
| Weight | 4800kg | Certification | CE | |
| After-sales Service Provided | Overseas service center available |
Product Description
Specifications
Soft Carbonated Drink Production LineCapacity:2000-24000BPH
PLC auto control
High quality, lower price and good sevice
Soft Carbonated Drink Production Line
Characteristics: It can carry out washing bottle, filling and capping in one machine. The whole machine designing is reasonable. The appearance is beautiful and the maintenance is convenient. It adopts hanging type conveying-bottle structure to make changing bottle model more convenient, faster and more easy. The main machine adopts advanced PLC control technology. The key electric elements are adopt international famous products.
Main technical parameter:
| Model | DCGF16-12-6 | DCGF18-18-6 | DCGF24-24-8 | DCGF32-32-10 | |
| Production capacity(500ml b/h) | 2000-3000 | 3000-4000 | 4000-6000 | 6000-8000 | |
| Filling precision | <5mm(liquid level) | ||||
| Filling pressure (MPa) | <0.4 | ||||
| Gathers the fat bottle specification(mm) | bottle diameter:50-100 height:150-310mm | ||||
| suitable cap shape | Plastic screw cap | ||||
| Total power(kw) | 1.2 | 3.75 | 5.6 | 6.2 | |
| Weight(kg) | 2500 | 3500 | 4500 | 6000 | |
| Overall dimensions(mm) | 2250*1700*2300 | 2400*1960*2300 | 3010*2180*2400 | 4000*2250*2500 | |
Washer
filler
Capper
sleeve labeling machine
Shrinking tunnel
