Disel generator Mobile Light Tower-RPLT6800

FOB Price

Negotiable / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Disel generator Mobile Light Tower-RPLT6800
1.Hydraulic
2.Long working time
3.Engine is Kubota.
4.Easy Maintenance.

Model RPLT6800
Technical Specifications
Mast
Maximum extention of mast	8m
Elevation	Hydraulic
Raising/lowing mast	Button(Hydraulic)
Stages	6
Turning angle	358 degrees non-continuous
Lamp
Total power of lamps	4×1000W
Type of lamp	Metal halide lamp
Light capacity	4×110,000 lumen
Voltage	230V
Frequency	50Hz
Lifetime of lamp	5,000hours
Working temperature	≤85°C
Connection Protection index	IP54
Characteristics of the generator
Model	RD-10K
Generator set Prime power	50Hz 6.7kW / 60Hz 8.4kW
Engine model	Japan KUBOTA D1105-BG / UK PERKINS 403D-11G
Intake system	Natural Aspiration
Engine type	Vertical 4-cylinder,liquid cooled Diesel
No.of cylinders	3
Standby power for 50HZ(1500rpm)	9.5KW/50HZ; 11.5KW/60HZ
Alternator	STAMFORD PI 044F
Alternator Type	Brushless,self-excitation
Voltage regulation	Automatic
Alternator Prime power(pf:0.8)	6.7KW/50Hz 8.4KW/60Hz
Voltage	230V
Frequency	50HZ / 50HZ
Fuel tank capacity	100L
Prime fuel consumption at 100% load	2.0L/h
Working hours	50hours
Trailer
Road trailer with hitch ball
Packing Dimension & Weight
Storage	2650mm × 1300mm × 2450mm
Working	2650mm ×2400mm ×8000mm
