Epoxy PV Panel
- Ningbo/Shanghai
- T/T
You May Like
Product Details
| Place of Origin | Zhejiang, China | Brand Name | Leacy | |
| Model Number | LCYP | Material | Other, Poly/Mono | |
| Size | Customizable | Number of Cells | Customizable | |
| Max. Power | 0.1W-5W |
Product Description
epoxy PV panel:
CE, ISO and ROSH certification.
Customize the special dimension and shape according your request.
Specifications:
Model | Output power(W) | Vpm(V) | Ipm(mA) | Voc(V) | Isc(mA) | Size(mm) | Type of solar cell | Quantity of solar cell(pcs) |
LCYP-0.4M | 0.4 | 4 | 100 | 4.8 | 110 | 60*65 | 125*125 | 8 |
LCYP-0.44P | 0.44 | 5.5 | 80 | 6.6 | 88 | 40.5*80.5 | 156*156 | 11 |
LCYP-0.55P | 0.55 | 5.5 | 100 | 6.6 | 110 | 50*100 | 156*156 | 11 |
LCYP-0.6M | 0.6 | 6 | 100 | 7.2 | 110 | Φ103 | 125*125 | 12 |
LCYP-0.7P | 0.7 | 6 | 120 | 7.2 | 132 | 70*105.5 | 156*156 | 12 |
LCYP-0.82M | 0.82 | 5.5 | 150 | 6.6 | 165 | 70*105.5 | 125*125 | 11 |
LCYP-0.9M | 0.9 | 6 | 150 | 7.2 | 165 | 92*110 | 156*156 | 12 |
LCYP-1.2M | 1.2 | 6 | 200 | 7.2 | 220 | 110*110 | 150*150 | 12 |
LCYP-1.2P | 1.2 | 6 | 200 | 7.2 | 220 | 85*130 | 165*165 | 12 |
LCYP-1.5M | 1.5 | 6 | 250 | 7.2 | 275 | 114*132 | 125*125 | 12 |
LCYP-1.5P | 1.5 | 6 | 250 | 7.2 | 275 | 90*160 | 156*156 | 12 |
LCYP-2.4M | 2.4 | 6 | 400 | 7.2 | 440 | 142*163 | 125*125 | 12 |
LCYP-3M | 3 | 18 | 170 | 21.6 | 187 | 145*195 | 125*125 | 36 |
LCYP-3.5M | 3.5 | 9 | 390 | 10.8 | 429 | 145*195 | 125*125 | 18 |
