Mini solar controller for light (Time /Light /Rain control)
- 5000 Pack / Packs per Month
- Ningbo
- T/T
You May Like
Product Details
| Place of Origin | Zhejiang, China | Brand Name | Leacy | |
| Model Number | LYRM | Application | Charger Controller | |
| Rated Voltage | Other, 6V/12V | Maximum Current | 5A |
Product Description
Mini solar controller for light (Time /Light /Rain control)
1-5A
Model | LYRML series |
Rated voltage | 6/12V |
Strong charging pressure | 7.4/14.8V |
Equilibrium charging | 7.25/14.5V |
Float charging pressure | 6.85/13.7V |
Under voltage | 5.4/10.8V |
Under recover voltage | 6.5/13.0V |
Non-load current | ≤6mA |
Charging circuit voltage drop | ≤0.2V |
Discharge circuit voltage drop | ≤0.1V |
Maximum charging current | 1A/3A/5A |
Maximum load current | 1A/3A/5A |
Controller protection | Overcharge/Over discharge/Over current/Short circuit/reversed |
Charge mode | PWM |
Using elevation | ≤5500m |
Working temperature | -20℃ ~ 55℃ |
Gross weight (Kg) | 0.05Kg |
Net weight (Kg) | 0.035Kg |
Dimension | 79.5*52*21.5mm |
Protection level | IP22 |
Advantage function | Time control/Light control/Rain control |
