Vertical Continuous Plate Chain Type of Bucket Elevator in Low Price
- Shanghai
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
China Manufacturer Advanced Energy Efficient Bucket Elevator
-
China Reliable and Excellent Quality Ring Chain Factory Price Bucket Elevator for Cement Plant
-
China Vertical Industrial Small Cement Bucket Elevator for Cement Plant
-
China Professional Large Capacity High-strength Rubber Belt Bucket Elevator
-
Large Capacity NE Bucket Elevator Conveyor for Power Plant
-
Long Life Service Chemical Industrial Bucket Elevator
Product Details
| Place of Origin | Hubei, China | Brand Name | TianYi | |
| Model Number | TB | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Vertical Continuous plate Chain Type of Bucket Elevator in low price
TB(NE) Series Bucket Elevator, the full name is plate type sleeve roller chain bucket elevator (Plate chain bucket elevator for short),with the plate sleeve roller chain, it suits for conveying those dry, loose and easy to throw materials such as coal, gravel, ore, pebbles, etc., the temperature of the material is no more than 250℃.
Capacity of this model is 16 ~ 48 m³/h, lifting height is 5 ~ 40 m.
Main Features
1 Wide range of bulk materials can be handled, including powder, granular and block materials .
2 Large capacities for conveying in a compact space .
3 Completely enclosed for dust-tight operation,improve the working conditions and prevent the environmental from
being polluted.
4 Reliable electrical device and mechanical safety device .
5 Flexible installation and maintenance .
6 Construction available in carbon steel, stainless steel .
7 Engineered and manufactured to meet specific customer requirements .
Machine Parts
Name: Plate link chain & buckets
Brand: TIANYI
Original: CHINA
Main Features
Name: steel buckets
Brand: TIANYI
Original:CHINA
Pre-Sales Service
* Inquiry and consulting support.
* Technical drawing support.
* View our Factory.
After-Sales Service
* Training how to install the machine, training how to use the machine.
* Engineers available to service machinery overseas.
Easy-maintenance Vertical Plate chain Bucket Elevator Conveyor
Heavy Duty Vertical Bucket Elevator With Service Platform
China manufacturer advanced energy efficient bucket elevator
