Factory Wholesale 6inch Wood Chipper Price,wood Chipper on Pto,wood Chipper for Sale

Model

BX42 wood chipper

BX62/BX62R wood chipper

BX92R wood chipper

Drive System

Direct drive, PTO w/ shearbolt

Direct drive, PTO w/ shearbolt

Direct drive, PTO w/ shearbolt

HP requirements for max. cap.

35-40

60-70

85-110

HP Range

18-50

30-100

65-150

Chipper Capacity

4" Dia. (max. 12" slab)

6" Dia. (max. 12" slab)

10" Dia. (up to 14" slab)

Chipper Housing Opening

4"x10"

6½" x 12"

10½" x 14"

Rotor Size

25"

30"

36"

Number of Rotor Knives

4

4

4

Knife Type

Hardened tool steel

Hardened tool steel

Hardened tool steel

Rotor Weight

110 lbs.

180 lbs.

280 lbs.

Feeding System Feed

Self Feed

Self or Hydraulic Feed

Hydraulic Feed

Mounting System

3 Point Hitch

3 Point Hitch

3 Point Hitch

Dimensions (Hopper Folded)

40"L x42"W x 60"H

50"L x 52"W x 74"H

54"L x 52"W x 88"H

Hopper Opening

20" x 20"

25" x 25"

25" x 25" (635X635mm)

Discharge Hood Rotation

360°

360°

360°

Discharge Hood Height

60"

74"

84"

Rated RPM

540-1000

540-1000

540-1000

Weight

425 lbs.(195KG)

BX62S-770 lbs(346KG)./BX62R-1070lbs (485KG)

1375 lbs. (620KG)

1.Rotor
At the heart of the Wallenstein BX Chipper is an oversize heavy duty rotor and reversible chipping blades. The large diameter rotor has a faster tip speed for improved chipping action and the heavy gauge steel keeps your momentum to power through 6” diameter tree trunks.

2.Blades
The reversible blades are precision cut tool steel and hardened, keeping a sharp cutting edge and maximizing the performance of the chipper.

3.Air Vents
Blowing force is maximized with air intake vents on the side of the chipper. Air enters through the vents and powers the chips out the chute up to 20 feet.

4.Twig Breaker Blower Paddles
Behind the blades are blower paddles with integrated twig breakers designed for greater output force and smaller chips exiting the machine. This provides more consistent chip size and allows you to propel the chips further.

5.Adjustable Chute
Easily control where you want the chips with the double adjustable Exit Chute. The chute swivels 360 degrees and the top deflector adjusts the distance.


6.Self-feeding Hopper
The self-feed hopper is designed to angle the brush against the rotor and blades, pulling the branches into the chipper.
