phase dimming ETL ip20 non waterproof 60w driver led plastic 12v
- 30000 Piece / Pieces per Month
- xiamen
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
500ma 35w dimmable led lighting driver for led panel lights
-
150w 24v 6.3a dimmable power transformer 220v 24v / led power supply
-
constant voltage dimmable electronic intertek led transformer 12v
-
Constant Voltage 12v dc transformer 96W switching power supply for Led Driver
-
320mA 350mA 500mA 700mA constant current LED driver
-
led driver UL ETL FCC listed ac dc Triac dimmable driver 36W 12V
Product Details
| Place of Origin | Fujian, China | Brand Name | SMARTS | |
| Model Number | SMT-012-060VT | Output Power | Other, 60w | |
| Output Type | Single | Input Voltage | Other, 90~135Vac/170~265Vac | |
| Output Voltage | 12Vdc | Output Frequency | 47-63Hz | |
| Output Current | 5.0A |
Product Description
etl cul ul 12v 60w constant voltage dimmable led strip light driver
model | SMT-012-060VT | SMT-024-060VT | |
Output | DC Voltage | 12V | 24V |
Voltage Accuracy | ±0.5V | ±0.5V | |
Rated current | 5.00A | 2.50A | |
Rated power | 60W | 60W | |
Input | Voltage Range | 90~135V AC/170~265V AC | |
Frequency Range | 47~63HZ | ||
Power Factor ( Typ.) | PF>0.95/110V,PF>0.96/170V,PF>0.95/220V,PF>0.93/265V | ||
Full Load Efficiency(Typ.) | >85% | >85% | |
AC Current(Typ.) | 0.61A/110VAC, 0.58A/170VAC, 0.46A/220VAC, 0.41A/265VAC | ||
Leakage current | <0.25mA/110V/220VAC | ||
Protection | Short Circuit | Hiccup mode, recovers automatically after fault condition is removed. | |
Over voltage | <140VAC(90~135V) , <270VAC(170~265V) | ||
Environment | Working TEMP. | -40~+60℃ | |
Working Humidity | 20~90%RH,non-condensing | ||
Storage TEM.,Humidity | -40~+80℃,10~95%RH | ||
efficient | ±0.03%/℃(0~50℃) | ||
Vibration | 10~500Hz,2G 10min./1 cycle,period for 60min. each along X,Y,Z axes | ||
Safety&EMC | Safety standards | EN-60950-1, EN61347-1/-2/-13 | |
Withstand voltage | I/P-O/P:3.75KVAC | ||
Isolation resistance | I/P-O/P:100MΩ/500VDC/25℃/70%RH | ||
EMC EMISSION | Compliance toEN55015,EN61000-3-2 (>50%load) | ||
EMC IMMUNITY | Compliance to EN55015; EN61000-4-2,3,4,5,6,8,11, EN61547 Alight industry level (surge4KV) | ||
Others | Weight | About 0.34Kg | |
Size | 180*60*34mm(L*W*H) | ||
packing | 324*298*176mm (L*W*H) | ||
Notes | 1. All parameters NOT specially mentioned are measured at 110V/230VAC input , rated load and 25℃of ambient temperature. 2. Ripple& noise are measured at 20MHz of bandwidth by using a 12”twisted pair-wire terminated with a 0.1uf &47uf parallel capacitor. 3. Tolerance:includes set us tolerance,line regulation and load regulation . | ||
- Input Brown with AC (L),Blue with AC(N),Green/Yellow with AC(G)
- Output Red is(DIM+),Black is(DIM-)
- Note: Any other requests we can customized.
Dimming Operation
- Output constant current level can be adjusted through input terminal of the AC phase line(L) by connection a triac dimmer.
- Compatible with Leading edge or tailing edge triac dimmers.
- please try to use the small power dimmer, have access to a wider dimming range, high-power dimmer is difficult to achieve the output current to zero
Derating Curve
- Load carried in accordance with the load derating curve, according to the ambient temperature derating, in order to extend the running life.
Connecting Diagram
Simple Connection Diagram
We can supply you ETL approved Junction boxes for all kinds of the LED drivers.
| N.W./pcs | G.W/ctn | Qty/ctn | Carton Size(mm) | ||||
| phase dimming ETL ip20 non waterproof 60w driver led plastic 12v | |||||||
| 0.34kg/pcs | 20kg/ctn | 30pcs | 324**298*176mm | ||||
MOQ: 1 pcs Payment: Delivery: 7 working days for sample order,12 working days for 500pcs Shipping term: FedEx, DHL, UPS, TNT... Price: Get quote |
