KDON-550-200 Air Separation Plant Oxygen Nitrogen System
Negotiable
1 (Min. Order)
- SHANGHAI PORT
- T/T
You May Like
Product Details
| Condition | New | Place of Origin | Jiangsu, China | |
| Brand Name | XAL | Model Number | KDON-550-200 | |
| Usage | Oxygen | Production Rate | 99.5-99.99% | |
| Certification | ISO9001:2008/CE/ASME | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Product Description
KDON-550-200 Air Separation Plant Oxygen Nitrogen System
the technical parameter of product:
| Name | Output | Purification | Operating Pressure |
| Oxygen | 550m3/h | ≥99.6%O2 | 0.55MPa |
| Nitrogen | 200m3/h | ≤3ppmO2 | 0.55MPa |
Start-up time: ~36h
Power consumption: 0.65KW.h/M3O2
Operational cycle time: 12 months
1 WHY CHOOSE US
a. we have senior team
| Technical Title | Technical engineers | Senior engineers | Professional senior engineers |
| Quantity(individual) | 85 | 30 | 10 |
b.we have got many patents
c.we have large selling realm
Covering internal and international area
and exported to about 30 countries such as North America, Europe, Asia and Africa.
and exported to about 30 countries such as North America, Europe, Asia and Africa.
2 HOW WE WORK
a. Purifying air buy using air filter to eliminate the dusk and mechanical admixture.
b. Using the air compressor to compress air at a needed point.
c. Using the pre-cooling system to cool the air with normal temperature makes the molecular sieve adsorbent in good condition.
d. After cooling by pre- cooling system.the air is putted into MS system to adsorb the water,CO2 and HC to extend life span of expander,heat exchanger in cold box.
e.Finally,the totally purified air be carrying into cold box to rectify,which separates oxygen and nitrogen product using the different boiling point.
b. Using the air compressor to compress air at a needed point.
c. Using the pre-cooling system to cool the air with normal temperature makes the molecular sieve adsorbent in good condition.
d. After cooling by pre- cooling system.the air is putted into MS system to adsorb the water,CO2 and HC to extend life span of expander,heat exchanger in cold box.
e.Finally,the totally purified air be carrying into cold box to rectify,which separates oxygen and nitrogen product using the different boiling point.
3 ITEMS DETAILS
a. Air compressor and pre-filter system
air is compressed by compressor, which our company specially uses air booster compressor to increase efficiency. the follow is a picture of centrifugal air compressor of our company.
air is compressed by compressor, which our company specially uses air booster compressor to increase efficiency. the follow is a picture of centrifugal air compressor of our company.
b. Air pre-cooling purifying system
After compression and water separation.air into pre-cooling unit to pre cool.Our company specialized in using waste nitrogen pre cooling system.
After compression and water separation.air into pre-cooling unit to pre cool.Our company specialized in using waste nitrogen pre cooling system.
c.Air purification system
air enter into the molecular sieve purify system to adsorb water,CO2 and HC,the adsorbers of our enterprise are all used double decker structure,which can adsorb impurity one hundred percent.
d.Distillation system
The purified water are putted into cold box to rectify,after expansion refrigerator distillation of air ,we can get the product of 99.6 %oxygen,and 99.99%nitrogen.
The purified water are putted into cold box to rectify,after expansion refrigerator distillation of air ,we can get the product of 99.6 %oxygen,and 99.99%nitrogen.
3 KDON System’technical parameter
Plant model |
Oxygen capacity Nm3/h |
Oxygen purity % |
Nitrogen capacity Nm3/h |
Nitrogen purity PPmO2 |
| KDON-1000/1350 | GO2:1000 | 99.6 | GN2:1350 | ≤10PPmO2 |
| KDON-750/1400 | GO2:750 | 99.6 | GN2:1400 | ≤10PPmO2 |
| KDON-550/200 | GO2:550 | 99.6 | GN2:600 | ≤10PPmO2 |
| KDON-350/600 | GO2:350 | 99.6 | GN2:900 LN2:50L/h | ≤10PPmO2 |
| KDON-250/900(50Y) | GO2: 250 | 99.6 | GN2:900 LN2:50L/h | ≤3PPmO2 |
| KDON-170/100 | GO2:170 | 99.6 | GN2: 100/0.6MPa | ≤10PPmO2 |
| KDON-80/40 | GO2:80 | 99.6 | GN2: 40/0.6MPa | ≤10PPmO2 |
4 Our part Certificates:
PLEASE CONTACT US:
PC: 215131
TEL: 86-512-65766331/65767253/65769056
FAX:86-512-65767057
Contact Us
- Suzhou Xinglu Air Separation Plant Science & Technology Development Co., Ltd.
- Contact nameAlex Xue Chat Now
- Phone86-512-65769056
- Address989 Chengbo Road, Xiangcheng District, Suzhou City, Jiangsu Province. China, Suzhou, Jiangsu
