Home > Products > Rubber tile press machine > Rubber tile hydraulic Press Machine
Rubber tile hydraulic Press Machine
- 60 Set / Sets per Month
- qingdao port or any port of china
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
Condition | New | Type | Vulcanizer | |
Place of Origin | Shandong, China | Brand Name | HONGHESHENG | |
Model Number | HHS-9 | Voltage | 380V/220V/450V | |
Power(W) | 7.5KW | Dimension(L*W*H) | 2200*900*2200 | |
Weight | 3600kgs | Certification | CE ISO | |
Warranty | 2 years | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Rubber tile hydraulic Press Machine
rubber tile vulcanizing press is used to press the rubber tiles and rubber mats, it is good for using the recycling rubber.
.four colomn type rubber floor tile mould machine
1 Technical Parameters
S.no | Model | XLB-D550×550×4/0.5MN | XLB-D650×650×2/0.5MN |
1 | Nominal clamping force (MN) | 0.5 | 0.5 |
2 | Heating platen size(mm) | 550×550 | 650×650 |
3 | Plate clearance (mm) | 150 | 150 |
4 | Working layers | 4 | 2 |
5 | Piston stroke (mm) | 400 | 400 |
6 | Plate unit area pressure (Mpa) | 1.65 | 3.20 |
7 | Overall dimension (mm) | 2200×900×2200 | 2200×1200×2400 |
8 | Weight (kg) | 3600 | 5000 |
3 Features:
Manual push-pull mold
High output and efficiency
Easy and safe operating
4 The Detailed Parameter:
1. we usually design as clients' products and details request. our machine is 4 working layers, 1 hour can made 8 pcs rubber floor. We can also according your needs. and decide the working layers.
2.the machine is matched with manual push-out device .
3. we also can provide the different size of the molds, from 20mm to 75mm thickness.
4. rubber mixer can also provided, if needed.
5. The press with 12 pcs molds and rubber mixer is only 8m3 of the flooring area, it can be LCL for loading, So the sea freight is very cheap.
6. We also can according to the customers' requirement, and design the non-standard type of rubber tile vulcanizing machine.
4 detailed pictures
note : or choose bigger machine(steam heating system),produce 4 pcs a time,only 1 layer,tell me which machine you like when sending enquiry
5 mould
6 rubber tile picture and use
7 our working machine in factory,when you visit our factory, we can show you our machine in real production nearby factory.
For FCL goods, we usually pack machines with stretched film and then load them to the
container. to ensure safety, we will fix machine with steel .
For LCL goods, we usually pack machines with standard wood boxes first, and then they will be transported .
1 Guarantee : 2 years ,manufacturer sell, We offer lifetime technical support
2After sales:
1 once problems appear, we will reply in 24 hours. And give solutions
2provide facory layout drawing . Engineers available to service machinery overseas; Send the engineers to debug the machines
.
Qingdao Honghesheng Industry Co., LTD, manufacturer of rubber machine,which is located in the west coast of Qingdao economic district, with 10 million registered capital. The company covers an area of 5000 square meters with 26 professional and technical staffs and 5 senior engineers. The technical staffs have working experience in large tire enterprise who can design more suitable equipment for the customer as for tire production process. Also they can provide new factory site planning and other services.
The company’s main products are: Rubber kneader, rubber mixing mill, rubber sheet cooling machine, inner tube production line,tyre production line, vulcanizing press, waste tyre recycling plant…
welcome to visit our factory!
1. Q: Are you a manufacturer or training company?
A: We are the manufacturer. We have our own plant,worker and techniques research developing department.
2 .Q: Where is your factory located? How can I visit there?
A: Our factory add is Tieshan industrial Park, Jiaonan, Qingdao, Shandong province, China.
Nearest airport is Qingdao liuting international airport
Kindly send plane information in advance, so that we can pick you up at the airport, and book hotels as you require.
3. Q: What are your hot sale machine?
A: Our rubber and plastic machines are popular in the foriengn market. And main products are tyre recyling plant ,press machine and other machine.
4. Q: How does your factory do regarding quality control?
A: Quality is priority and we have our own quality control department. We win make a strick inspectin before the machines leave the factory.
5 .Q: Are the techncal parameter is fixed?
A: Basically, each model corresponding to the related machine. But we can design different type machine according to the client’s requirement.
6 How to send us your enquiry? Kindly tell me answer
-1 what is your rubber tile size ? 500*500mm?1000*1000mm?
-2tile shape? better send tile picture or drawing?
-3 Leave your cellphong? Skype? whatsApp?viber? so that we can talk efficiently
Contact Sophie for quotation NOW:
Skype: sophie.xiao3
Cell: +8613573826806 (whatsApp and viber)
