Pug mixer, Pug continuous mixer

Specifications

Pug continuous mixer, Pug mixer

Video:  /videoLDHC2.html

1.  Working principles:

 LDHC  Plow  Mixing agitator  is widely  used  in the mixture of  chemical materials,  pigment, pharmaceutic materials,  feedstuff,  especially in the mixture of  fragile solid  grain;  In a short  time,  the  mixer  has good  mixing  effect  for  the materials  which  has a  great  difference in grain and density.
Its coulter  rotates together  with main axis and makes  the materials radial circling  flow  along the wall;  the radial materials flows through flying cutters,  and falls apart  by rotating  flying cutters;  the materials can  be mixed uniformly  in a shorttime.

2. Application:
Powder-Powder , Powder-Grain , Powder-Liquid, Grain-Grain etc.

3. Options:
(1) Motor: Ordinary motor , Explosion-proof  motor , Frequency  conversion  motor.
(2) Decelerator:  Xseries  gear decelerator , Cycloid decelerator ,  Worm decelerator.
(3) Discharging  valve:  Flap  valve , State  standard  valve , Cylinder  valve ,  Non-standard  discharging  valve.
(4) Control:  Manual  control , Pneumatic  control , Electric control.
(5) Feeding inlet: Standard , Designed as  requirement ,  Manual  feeding  inlet (  with cover ).

4. Seal:
Teflon , Mechanical ,  Air purge.

5. Material:
Mild steel ;  Stainless steel ( 304,316,316L etc.).

6. Additional functions:
Outer jacket , Heating  jacket , Tube temerature-control  jacket , Temperature  preservation layer ,  Batching  type , Sprinkling device,  Heavy duty  type.
