YT Series Multicolor Flexographic Printing Machine
- NINGBO
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
YT-4-600 High Quality Best Sale Flexo Printing Machine Manufature
-
YT-4-800 Ruian Full Automatic 4 Color Flexo Printing Machine
-
YT-4-800 China Brand Best Sale 4 Colour Flexo Printing Machine
-
YT-6-1200 High Speed Six Color Flexo Printing Machine
-
YT Series High Quality Flexo Printing Machine
-
YT Series High Speed Flexo Printing Machine
Product Details
| Condition | New | Plate Type | Other, Flexographic Printing Machine | |
| Place of Origin | Zhejiang, China | Brand Name | Duke | |
| Model Number | YT Series | Usage | Paper Printer, Label Printer, Card Printer, Tube Printer, Bill Printer, Cloths Printer, Other, Paper Printer, Label Printer, Card Printer, Tube Printer, Bill Printer, Cloths Printer, multi-function | |
| Automatic Grade | Automatic | Voltage | 380/220 | |
| Gross Power | 22KW | Dimensions(L*W*H) | 3850X1850X2250mm | |
| Weight | 3.7T | Certification | CE | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
Multicolor Flexographic Printing Machine1.EPC,Auto Tension Control
2.High Speed 100m/min
3.Have Stock
4.Free technic suppe
Multicolor Flexographic Printing Machine Specification:
Flexographic printing machine, also called aniline press which uses photosensitive resin plate as the printing plate of printing machine. It adopts environmental ink and has advantage of low edition-producing cost, this is an ideal machine for mass lots, large variety production manufacturer It is also suitable for printing HDPE, LDPE, PP. cellophane paper, rolling paper etc.
Flexographic Printing Machine Technical Parameters:
Two Color Flexo Printing Machine:
Type | YT-2600 | TY-2800 | YT-21000 |
Max. Width of Printing | 550mm | 750mm | 950mm |
Max. Printing Length | 914mm | 914mm | 914mm |
Max Diameter of Printing Length | Φ450mm | Φ450mm | Φ450mm |
Printing Speed | 5-60m/min | 5-60m/min | 5-60m/min |
Printing Color Number | 2.4.6 | 2.4.6 | 2.4.6 |
Format Mater Thickness | 0.02-0.06mm | 0.02-0.06mm | 0.02-0.06mm |
Total Power | 19kw | 19kw | 19kw |
Machine Weight | 1.5T | 2T | 2.5T |
Overall Dimensions(L×W×H)mm | 3850×1850×2250mm | 3850×2050×2350mm | 3850×2250×2350mm |
Best Sale Flexographic Printing Machine With Four Color Specification:
Type | YT-4600 | TY-4800 | YT-41000 |
Max. Width of Printing | 550mm | 750mm | 950mm |
Max. Printing Length | 914mm | 914mm | 914mm |
Max Diameter of Printing Length | Φ450mm | Φ450mm | Φ450mm |
Printing Speed | 5-50m/min | 5-50m/min | 5-50m/min |
Printing Color Number | 2.4.6 | 2.4.6 | 2.4.6 |
Format Mater Thickness | 0.02-0.06mm | 0.02-0.06mm | 0.02-0.06mm |
Total Power | 19kw | 19kw | 19kw |
Machine Weight | 3T | 4T | 4.5T |
Overall Dimensions(L×W×H)mm | 3850×1850×2250mm | 3850×2050×2350mm | 3850×2250×2350mm |
Multicolor Flexographic Printing Machine 6 colors:
Type | YT-6600 | TY-6800 | YT-61000 |
Max. Width of Printing | 550mm | 750mm | 950mm |
Max. Printing Length | 914mm | 914mm | 914mm |
Max Diameter of Printing Length | Φ450mm | Φ450mm | Φ450mm |
Printing Speed | 5-50m/min | 5-50m/min | 5-50m/min |
Printing Color Number | 2.4.6 | 2.4.6 | 2.4.6 |
Format Mater Thickness | 0.02-0.06mm | 0.02-0.06mm | 0.02-0.06mm |
Total Power | 22kw | 30kw | 30kw |
Machine Weight | 3.7T | 4.5T | 5T |
Overall Dimensions(L×W×H)mm | 3850×1850×2250mm | 3850×2050×2350mm | 3850×2250×2350mm |
Skype: ritayuan99
Trade Manager : cn1000514614
Tel:+0086-13967712895
Flexographic Printing Machine Optional Device:
1.PLC
2.Flexo Printing Ceramic Anilox Roll
3.Air Shaft
4.EPC
Flexographic Printing SAMPLE:
Flexographic Printing Machine Ceramic Anilox Roll :
Flexo Printing Machine Blade :
Flexographic Printing Machine helical tooth:
Flexographic Printing Machine Air Shaft:
The Flexo Printing Machine Detail Pictures:
Flexographic Printing Roll:
Flexo Printing Machine For Plastic Film :
Multicolor Flexographic Printing Machine For Paper Print pictures:
Printing Machine For Nonwoven Material:
Multicolor Flexo Printing Machine Real Machine Photos :
helical tooth 4 Color Flexographic Printing Machine:
6 colors Flexographic Printing Machine Real Photos: for 1200mm width
Company Photos:
