Rubber Solar Collector Pool Heating With Solar Keymark

FOB Price

USD $150 - $400 / Set

1 Set(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Type	Evacuated Tube	Pressure	Pressurized
Circulation Type	Direct / Open Loop (Active)	Heating System	Batch / ICS (Passive)
Connection Type	Direct-Plug	Installation	Freestanding
Housing Material	Other, Galvanized steel/Stainless steel	Certification	CE
Capacity	200	Place of Origin	Zhejiang, China
Brand Name	GAODELE	Model Number	GDL-CPSS-20-200

lar collector
2.best quality solar collector manufacturer
urized solar collector
4.low price solar collector

Rubber Solar Collector Pool Heating With Solar Keymark

solar collector Material and Features:

solar collector Tank	Inner Tank Thickness	1.5 mm/1.8mm/2.0mm
	Outer Tank Thickness	0.5 collector mm
	Inner Tank Material	SS 304
	Outer Tank Material	Galvanized steel/Stainless steel
	Color	According to customers'
Solar collector Bracket	Bracket Material	Galvanized steel Powder Coated
	Thickness	1.2mm
	Color	According to customers'
Solar collector Reflector	Material	stainless steel/Aluminium Alloy
Solar collector Reflector	Type	Strip Type
Solar collector Insulation	Material	PUF
Solar collector Insulation	Thickness	50 mm
Solar collector Capacity	100,150,200,250,300,400,500 Liters
Solar collector Warranty	5 years

solar collector vacuum tube Material and Features:

Tube structure		All-glass double-tube co-axial structure
Glass material		Borosilicate 3.3glass
Outer tube diameter and glass thickness		Φ =47± 0.7mm & T=1.6mm ± 0.15mm
Outer tube diameter and glass thickness		Φ =58± 0.7mm & T=1.6mm ± 0.15mm
Inter tube diameter and glass thickness		Φ =37± 0.7mm & T=1.6mm ± 0.15mm
Inter tube diameter and glass thickness		Φ =47± 0.7mm & T=1.6mm ± 0.15mm
Tube length		1500mm, 1800mm
	Coating material	AL-N/SS/Cu
Absorber coating	Sediment method	Three Targets magnetron sputtering plating
	Absorption	a: ≥92%(AM1.5)
	Emittance	ε ≤ 3.4% (80° C± 5° C)
Vacuum degree		P ≤ 5.0× 10 -3 Pa
Hail resistance		Φ 25 mm
Pressure-endure		0.8 Mpa
Temperature-endure		250° C
Life		> 15 years

solar collector Working Principle:

solar collector Details Pictures:

solar collector Loading Ability:

solar collector Thickness Measure and Argon Welding

solar collector Main Production Line

solar collector Quality Control

solar collector Certificates

Solar collector Exhibition
