7.0 Inch TFT LCD Night Vision Camera 2.4GHz Digital Wireless Baby Monitor Kit

7.0 Inch TFT LCD Night Vision Camera 2.4GHz Digital Wireless Baby Monitor Kit

Introductions:
Ultimate safety wireless baby monitor set, coming with a high quality 2.4GHz wireless receiver with Ultra-large 7.0 inch screen plus 2 Wireless Night Vision Cameras for keeping a very close eye on your baby or rooms. This wireless receiver works in ISM Band:2400-2485MHz to receive wireless camera audio and video signals and displays the received image signal on the LCD screen. With our Monitoring System software, you can capture the image and video you are watching, and play back the data recorded. You can  enjoy its capability for entertainment, monitoring and security purposes.

Features:
1.2.4GHz wireless 7.0 inch TFT LCD monitor with remote control
2.380 TV lines clear picture display
3.4-Channels available to avoid interference
4.Built-in 24 infrared LED lights enables you to view up to 15 meters at night or in low-light settings
5.Built-in microphone for audio monitoring
6.100m transmission distance without block
7.Suitable for monitoring children and elders, and widely used for theft prevention, after-hours surveillance, home security, etc.
8.Channel scan and channel skip for multi-camera usage
9.Weather-proof camera

Specifications:
General
1. Transmission Frequency: ISM 2400MHz~2483MHz  4CH
2. Modulation Mode: FM
3. Antenna Type: Camera: Omni; Receiver: Directional
4. Unobstructed Effective Range: up to 100m(Without Block)
5. Antenna Port: 50ohm SMA
6. Operating Temperature: 0℃~+50℃
7. Storage Temperature: -20℃~+60℃
8. Operating Humidity: 85%RH

Camera:
1. Imaging Sensor Type: 1/4" CMOS
2. CMOS Total Pixels: 510X492(NTSC)
3. Horizontal Definition: 380 TV Lines
4. View Angle: NTSC:46°
5. Minimum Illumination: 5.0 Lux / F1.2&0 Lux(IR ON)
6. Transmission Power: 80 mW
7. Power Supply: DC 5V 1000 mA
8. Night Vision Range: 15m
9. Consumption Current: 80 mA & 200 mA (IR ON)
10. Dimensions: 5.7 x 11.5(Dia. x H)

Receiver:
1. LCD Type: TFT
2. LCD Screen Size: 7"
3. Dot Pitch: 0.1025mm x 0.163mm
4. View Angle(U/D/L/R): 10°/30°/45°/45°(Min)
5. Brightness: 300 cd/square meter
6. Contrast Ratio: 150:1
7. Interface: Alternated Video Signal
8. Light Source: CCFL
9. Power Supply: DC 12V 1.5A
10. Video Output Level: 1Vp-p@75ohm
11. Audio Output Level: 1Vp-p@600ohm
12. Receiving Sensitivity: ≤-85dBm
13. Dimensions: 18.9 x 2.1 x 14cm(L x W x H)

Package Includes:
1 x Receiver
2 x Camera
1 x Receiver Adapter
2 x Camera  Adapter
1 x AV Cable
1 x Antenna
1 x Remote Control
1 x Users Manual
