2014 Hottest Electric Control Lock for Wooden Door Transmitter Lock

Specifications

Electric rim lock description:

1.Elecreic motor lock specially designed for door-closing system,remote control system and etc,adopting CPU automatic control

2.Available different kind of door

3.No necessary to identify installation directions

4.No need wirings to install,battery supports

5.Low noise,no shock,Low consumption,long life,simple way to install,just drill four holes

6.Electric rim lock, noiseless when locking,and automatically lock when the door is closed

7.Made of top quality metal ensure to provide durable security, reliability & safety to the user

8.2000 user cards meet the demand of application in different place,such as: metal door and wooden door, house, factory, shop and warehouse, etc.

Electric rim lock technical parameters:

Electric rim lock advantages & features:

1.This electric control lock work alone,no need with power supply

2.no cables conect other element

3.Two ways to open, card to open, and mechanical key to open

4.Four batteries support 8 months work

5.High security and low noise

6.Uitra quiet when operation

7.Can independently cancel user card through infrared ray remote control panel

8.The product adopt newest patent technology,having incomparable advantages from tradition electric locks

9. Electric motor lock is very easy to install,regardless of left and right sides.

10. Locks of security can work with door closer

11. The unique card function, operation more convenient

Electric rim lock details:

Electric rim lock installation:

Operations of Add and Delete Card:

1.Add the general user card:Swipe admin card once→then swipe a blank card as user card→add user card successful→swipe admin card again or wait a few seconds to automatically exit;

2.Delete user card: Swipe admin card twice→then swipe the user that need to delete→delete successful→Swipe admin card again or wait a few seconds to automatically exit;

3.Add normal open card: Swipe admin card three times→then swipe a blank card that need to add→add successful→ swipe admin card again or wait a few seconds to automatically exit;

4.Add double-lock open card: Swipe admin card four times→then swipe the blank card that need to add→add successful→Swipe admin card again or wait a few seconds to automatically exit;

Operation manual for different cards:

Admin Card: The admin card is preset from factory, used for managing user cards. Please keep this card carefully.

User Card: Only used to open lock which is not double locked. Automatically lock up when door not open last for 10 seconds

Normal Open Card: The first time swipe card to open, but lock can’t auto-lock itself. If want to lock, need to swipe card again.

User card for double lock: The card can open locks which are double locked inside. If you don’t push open the door after it is unlocked within 10 seconds, the lock will auto lock.

Infrared Remote Card management:

Add user card: Swipe any card to start the infrared remote control function→press CALl , after buzzing tone the lock enters into the programming process,

input the admin password (the initial password is 12345678) +# →press the remote control 1# →swipe card needed to add → add successfully.

Delete user card by swiping card: Swipe user card to start the infrared remote control function → press CALL , after buzzing tone the lock enters into the programming process,

input the admin password (the initial password is 12345678)+# →press the remote control 2#→swipe card needed to add → delete successfully.

Delete User Card by input card series NO.: Swipe user card to start the infrared remote control function → press CALL , after buzzing tone the lock enters into the programming process,

input the admin password (the initial password is 12345678) +# →press the remote control 5#→ input user card 10 card number+# → delete successfully (can delete several cards at one time).

Add Normal Open Card: Brush any card to start the infrared remote control function → press CALL , after buzzing tone the lock enters into the programming process,

input the admin password (the initial password is 12345678)+#→ press the remote control3#→add one or several cards at one time → add successfully.

Modify the administrator password: Brush any card to start the infrared remote control function →press CALL , after buzzing tone the lock enters into the programming process,

input the admin password (the initial password is 12345678)+# →press the remote control 4# →input 8-digit new admin password+#→ modify successfully.

The ways to initialization reset (In case of forget admin password or lose admin card):

Open battery cover, find the reset button next to electric lock edge. Press the reset button until electric lock beeps, then swipe a card as the admin card.

And meanwhile, the admin password will be renewed as initial password 12345678.

Electric rim lock series:

Customer and us:

Payment:

If the total amount is less than 500USD,we prefer to accept PayPal or Western Union;for big amount we accept bank transfer.

Shipment:

Normally we will use UPS,DHL,FEDEX or EMS express.It usually takes 3-7 working days depending on the countries deliver to.

We can also arrange other shipment way per your requirement and instrution ,such as sea shipment,air shipment ,etc.

Warranty:

Warranty for one year,maintenance forever,change within 3 mounths because of product quality.
