Ring Illuminated square Push Button Switch 22 (dia.22mm)
USD $3.5 - $4.8
/ Piece
10 Pieces(Min.Order)
- 100000 Piece / Pieces per Month
- Ningbo/Shanghai
You May Like
-
QN22-A1black aluminum white ring led pin plated gold push button switch
-
High quality 22mm 12v dc automatic transfer switch 6 pole push switch
-
High quality QN22-JM 2NO2NC arrow symbols emergency switch low voltage switch
-
High quality 22-F3 2 step double pole double throw porn push button switch
-
22 mm ring led momentary new type push button switch
-
22mm push button switch with connector , switch socket with cable
Product Details
| Place of Origin | Zhejiang, China | Brand Name | QN | |
| Model Number | QN22-A | Protection Level | IP65 | |
| Max. Current | 5A | Max. Voltage | 250V |
Product Description
Specifications
Anti-vandal Long-life Metal Push Button Switch| Mounting hole: Φ22mm diameter |
| Operation type: Latching / Momentary |
| Contact Configuration: 1NO 1NC |
| Front Shape:Flat Round |
| Terminal Type: Pin Terminal |
| Max. Switch Rating: 5A/ 250V |
| Contact Resistance: ≤50mΩ |
| Insulation Resistance: ≥1000mΩ |
| Dielectric Strengh: 2000VAC |
| Operation Temp.: -20°c ~ +55°c |
| Mechanical Life: 1,000, 000cycles |
| Electrical Life: 50, 000cycles |
| Panel Thickness: 1~8mm |
| Torque: 5~14Nm |
| Operation Pressure: About 5.5N |
| Operation Travel: About 2.5mm |
| IP Degree: IP65, IK10 |
| Contact Material: Silver Alloy |
| Crust Material: Stainless Steel |
| Button Material: Stainless Steel |
| Body Material: Stainless Steel |
| Base Material: PA66 |
| LED spec.: Ring Illuminated |
| LED rated Voltage: 3V/6V/12V/24V/110V/220V |
| LED Color: R/G/Y/B/W |
| LED Life: 40000 hours |
