Home > Products > Quartz Crystal > 2.0x1.6mm SMD Quartz Crystal-Smart House
2.0x1.6mm SMD Quartz Crystal-Smart House
- Taipei
You May Like
Product Details
| Place of Origin | Taiwan, China | Brand Name | Ansen | |
| Model Number | ASX1F |
Product Description
Ansen Quartz is the leading supplier of crystals and oscillators in Taiwan. Our R&D department has applied the state of art technology in the field of crystal oscillator performance, precision and reliability to be in line with the top tier market trend. We offer highly precise, highly reliable frequency control and be able to provide customized products. Offering satisfactory after-sale services is also our objective. We are ISO9001 certificated, and constantly deliver the best quality products and efficient services to the worldwide customers. Ansen Quartz offers customer satisfaction.
1. SMD XTL (smallest size up to 1.6x1.2 mm)
2. SMD Oscillator (smallest size up to 2.0x1.6 mm)
3. LVDS/LVPECL Oscillator (7x5, 5x3.2, 3.2x2.5mm)
4. HCSL Oscillator (7x5, 5x3.2mm)
5. 32.768KHz Oscillator (7x5, 5x3.2, 3.2x2.5, 2.5x2.0mm)
6. LOW EMI (7x5, 5x3.2mm)
uCertifications :
1. ISO 9001:2008
2. ISO 14001:2004
3. IECQ/QC 080000:2005
4. RoHS/REACH compliant.
u Applicaton:
Any customize requirements please contact Ansen sales team for price and detail specification.
