Product Details
| Place of Origin | Guangdong, China | Brand Name | CND | |
| Model Number | MDV6822 | Type | TFT |
Product Description
Specifications
1.MDV6822 Main Board With DVI VGA And Audio Power Amplifier2.Low cost
3.High quality
4.ISO9001:2008
5.Full range
MDV6822 Main Board With DVI VGA And Audio Power Amplifier
General descriptions:
The board is used for match TFT LCD panel , Come true LCD display or advertising machine, digital photo frame, supports a maximum resolution of WUXGA (1920X1200) point-to-point display the resolution is up to 1920X1200, Input signal is analog VGA R,G,B and DVI input , Its color reach 24 bit potentially. H-Frequency signal range from 30 to 94.5 KHz, V-Frequency signal 56 to 75 Hz. synchronize automatic detection. The synchronization approach requires use of the separation of the horizontal and vertical synchronization signals.
The product provide audio power amplifier at the same time, the output power of 2W × 2, can be controlled by a key way of numerical to adjust the volume.
Specification:
Feature | Specification |
Input signal: | Analogy RGB(0.7Vp-p), Horizontal and vertical sync separation(TTL) |
DVI:TMDS | |
Support model : | DOS, VGA, SVGA, XGA, SXGA+, UXGA, WXGA, WXGA+, WSXGA, WSXGA+, WUXGA etc |
Color : | 24bit |
Horizontal sync range : | 30-94.5KHz |
Vertical sync range: | 56-75Hz |
Output signal: | Dual LVDS standard |
audio output rate:1W×2 | 8ohm 2W×2 |
Control key-press:: | POWER,BRI+,BRI-,AUTO,NENU,LED_R,LED_G |
OSD menu: | Brightness, contrast, auto-correction, phase, clock, horizontal and vertical position, feature set, reset |
OSD language(optional): | Simplified Chinese, Traditional Chinese, English, French, German, Italian, Spanish, Portuguese, Dutch, Turkish, Korean, Japanese, Arabic, Persian, Russian, Thai, Vietnamese, Bahasa Indonesia |
Power supply input : | 12 V(+/-0.6V)(DC) Without the amplifier can be changed to 5V input |
Power supply operation: | Normal operating mode |
Size: | 107mm(L)×52mm(W)×16mm(H) |
Plug and Play function: | support |
power supply management :<3W | standby power consumption<1W |
Picture of product:
Packaging and warehouse stock:packaging with plastic bags and cartons.
Certifications:we have won authentication of ISO9001:2008 and won eight national patents.
Factory with professional workers and technical machines.
