10 Tons Automatic Decoiler/ Hydraulic Uncoiler
US$ 6,500 - 10,500
/ Set
1 Set(Min. Order)
- XINGANG TIANJIN
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
10 Tons Color Steel Coil Decoiler/ Uncoiler Machine
-
China Supplier Color Steel Coil 5 Tons Decoiler
-
DX Uncoiler,Decoiler,Hydraulic Uncoiler/roll Forming Machine Manufacturer
-
Best Price! Good Quality Hydraulic Decoiling and Feeding Machine With or Without Coil Car
-
Hydraulic Steel 10 Ton Uncoiler
-
Hydraulic Decoiler With the Small Car
Product Details
| Condition | New | Type | Decoiler | |
| Tile Type | Colored Steel | Use | Step | |
| Production Capacity | 10-15m/min | Place of Origin | Hebei, China | |
| Brand Name | DIXIN | Model Number | DX 10 TONS DECOILER | |
| Power(W) | 7.5kw | Voltage | 380V 50Hz 3phases | |
| Dimension(L*W*H) | 5m*1.3m*1.3m-15m*1.3m*1.4m | Weight | 3.2T | |
| Certification | ISO9001/BV Certification | Warranty | 1 Year | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
10 tons automatic decoiler/ hydraulic uncoiler
Application
This machine is used to hold coil, and uncoil it, and feed into roll forming machine. This machine can rotated clockwise and anti clockwith. Also the speed is adjustable. With the help of limit switch box, this uncoiler can work with roll forming machine synchronized. It greatly save the labours and improved the working efficiency.


Hydraulic decoiler, Manual decoiler, uncoiler, feeding machine
Main parameter:
1. Install size: 2700mm*1750mm*1700mm
2. The coil width: ≤ 1250 mm
3. Coil inside diameter: 480-510mm
4. Productivity: 0-35m/min
5. Main motor power: 3 KW
6. Hydraulic unit power: 3 KW
7. Electric control system: PLC vector inverter
8. Capacity: 5tons, 8 tons, 10tons
We also can design and manufacture as per your request.
Main parameter:
1. Install size: 2700mm*1750mm*1700mm
2. The coil width: ≤ 1250 mm
3. Coil inside diameter: 480-510mm
4. Productivity: 0-35m/min
5. Main motor power: 3 KW
6. Hydraulic unit power: 3 KW
7. Electric control system: PLC vector inverter
8. Capacity: 5tons, 8 tons, 10tons
We also can design and manufacture as per your request.
| Advantage of our decoiling machines |
| High quality |
| Lower cost |
| Durableness |
| High efficiency |
| Reliable working |
| Low failure rate |
| Low energy consumption |
| Trouble free after sales service |
