Home > Products > Stationary Asphalt Plant > LB800 Asphalt Plant Price for Sales IN Indonesia
LB800 Asphalt Plant Price for Sales IN Indonesia
- qingdao port
- T/T Credit Card
You May Like
Product Details
| Condition | New | Place of Origin | Henan, China | |
| Brand Name | Double Birds | Model Number | DLB40 | |
| Voltage | 380v,220v | Power(W) | 132.4kw | |
| Dimension(L*W*H) | 25*50m | Certification | CE,ISO | |
| Warranty | 15 months | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
LB800 Asphalt Plant Price for Sales IN Indonesia
Asphalt Plants configuration
1. Cold Aggregate Supplying System
4 storage bins and 4 belt feeder, one aggregate belt conveyer.
2. Slanting Belt Feeder
Slanting belt Feeder, middle filter sieve;
3. Drying drum
4. Burning system
1 set coal pulverizer machine, a set combustor burner, a set of fuel oil igniting system.
5. Hot aggregate elevator
Elevated by Single row of chain,special structure for outlet will reduce the abrasion and noises.
6. Dust catcher system
Cyclone dust catcher+water dust catcher
7. Mixing Assembly
a. A three-layer semi-structured Vibrating Screen Parameters:
b. Hot Metering system
c. Weighting warehouse
d. Mixing Plant
e. Asphalt spray system
8. Powder supply system
Powder temporary hopper,mine powder addition spiral conveyor ,power lift .
9. Pneumatic control system
Air compressor, cylinder,electromagnetic valve and a set of air pipe.
10. Asphalt supply system
40 m3 asphalt tank (middle size) one unit (include 1 set of induced draft machine, 1 set of hot water furnace, 1 set of dust remover and chimney), pipeline and pump, valve 1 set for each.
11. Electric control system
- Dimension of control room: 3x2.2x2.5m
40t/h stationary Asphalt Batching Plant/Asphalt Mixing Plant for sales
LB800 Asphalt Plant Price for Sales IN Indonesia
No. | Name | Specification |
1 | Model | MDHB40 Asphalt Mixing Plant |
2 | Type | Continuous Mix |
3 | capacity | 40 TPH(Standard Working Condition) |
5 | Fuel Consumption | Diesel consumption 5.5-7.0 kg |
6 | Weighing precision | hot aggregate ±0.5%; bitumen ±0.3% |
7 | Hot Asphalt Temperature | 130℃-165℃ (adjustable) |
8 | Air Emission | ≤100mg/Nm³ |
9 | Working Noise | ≤70db(A) |
10 | Operation | Full Auto/Manual Operation |
11 | Installation Power | 75kw (380V-50Hz) |
12 | Electrical Design | 220V/380V-50Hz |
13 | Plant Covering Area | 30m length, 16m width, max height point 6m |
14 | Traveling Chassis A | For Aggregate Supplying System |
15 | Traveling Chassis B | For Drying & Mixing System |
16 | Documents | Lay-Out/ Electric Circuit Diagram; Chinese-English Operation Manual; Qualification Certificate |
LB800 Asphalt Plant Price for Sales IN Indonesia
Other model for the Asphalt Batching Plant/asphalt plant :
ype | LB800 | LB1000 | LB1500 | LB2000 | LB2500 | LB3000 | LB4000 | LB5000 | |
Plant Capacity (standard conditions): | 64t/h | 80t/h | 120t/h | 160t/h | 200 t/h | 240 t/h | 320t/h | 400t/h | |
Mixer Capacity: | 800kg | 1000kg | 1500kg | 2000kg | 2500 kg | 3000 kg | 4000kg | 5000kg | |
Consumption (standard conditions): | Fuel | 5.5-7 kg/t | 5.5-7 kg/t | 5.5-7 kg/t | 5.5-7 kg/t | 5.5-7 kg/t | 5.5-7 kg/t | 5.5-7 kg/t | 5.5-7 kg/t |
Coal | 10-13 kg/t | 10-13 kg/t | 10-13 kg/t | 10-13 kg/t | 10-13 kg/t | 10-13 kg/t | 10-13 kg/t | 10-13 kg/t | |
Measurement accuracy | Aggregate: ± 0.3% filter: ± 0.3% Asphalt: ± 0.15% | ||||||||
1.Pre-sales Services:
Contact - Design - Discussion (email/call/chatting tools) - Offer - Visiting Invitation & Reception - Establish Primary Trust
2. Selling Services:
- Sending the confirmed design and foundation map for building foundation;
- Taking photos and videos of the production processes for customers’ reference
- Pre-assemble main parts together and test
- Paint color and Logo following customers’ requirements;
- Arrange customers to come to inspect the finished goods;
- lBook the shipping space in advance to ensure delivery on time.
- Monitor containers loading and packing, such as wooden boxes packing, steel wires reinforcement.
3. After-sales Services:
- Tracking the vessels and the estimated arriving date;
- Sending all necessary documents and assist to fetch the goods smoothly;
- Dispatch experienced engineers to installation & commission, and training;
- Regularly learning the equipment running situation;
- Remote control is available at any time;
- Warranty: 12 months
- Spare Parts: sending through DHL/FEDEX/TNT
