Road Marking Paint Price Glass Bead Machine

FOB Price

US$ 200 - 20,000 / Set

1 Set(Min. Order)

Port Qingdao port or other port in China
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Power(W)	Manual
Place of Origin	Henan, China	Brand Name	DOUBLE BIRDS
Model Number	DB-THP-I hand push thermoplastic road marking machine	Dimension(LWH)	1210890970mm
Weight	165kg	Features	hand push thermoplastic road marking machine
Certification	CE	Warranty	one year
After-sales Service Provided	Overseas service center available

Product Description

road marking paint price glass bead machine

	Item No.	DB-THP-I
1	Paint tank	55L
2	Glass beads bin	12L
3	Heating mode	Liquefied gas fue, infrared propone
4	Marking equipment	Manual screeding marking shoe,pressure casting, standard configuration150mm
5	Knife underframe material	carbon steel material
6	Marking width	100mm,200mm,250mm,300mm (at customers’option)
7	Marking thickness	1.8-3.0mm(adjustable)
8	Dimensions (LWH)	1210890970mm
9	Weight	165kg

small hand-push cold paint type

Main features

*More stable:

Through gravity adjustment, widened front wheel, the Marking Machine is more stable than traditional ones when marking 450mm zebra crossing.

*Lighter:

Through repeatedly gravity test, rechoose new shaft, the marking machine is much lighter, reduced operator’s working intensity. So the marking works is easier and more effectively.

*Easy to operate

Marking hopper’s operating range minimized from 300mm to 200mm, more accurately ,easier to control, therefore such problems as slow hopper withdrawal and uneven finishing

mark edge are solved.

1.Packed in plywood case or as request

2. Available shipment by :FOB Qingdao,China

3.Delivery time: 10days after advance payment or according to the order quantity.

1.inner hex screw 2.back plate 3.hex nut 4.cut plate 5.regulation plate 6.duck mouth plate

loosen the screw(1) on the back plate (2), move the back plate (2) up for thick, down for thinner.

After regulation fix the inner hex screw (1)

Pleae see picture below to show you answer, if you still do not understand, please send us e-mail to ask for operational
