Trailer Type Mobile Asphalt Plant For Sales 100t/h ,120t/h

FOB Price

US$ 150,000 - 200,000 / Set

1 Set(Min. Order)

Port Qingdao Port
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Place of Origin	Henan, China
Brand Name	Double Birds	Model Number	YLB1000
Voltage	220V/380V-50Hz	Power(W)	156-276kw
Certification	ISO14001	Warranty	12 months
After-sales Service Provided	Engineers available to service machinery overseas

Product Description

Trailer type Mobile Asphalt Plant For Sales 100t/h,120t/h

A. Basic Configuration
1.Cold aggregate supply mobile modular (include elevator)
2.Inclined belt feeder
3.Dry drum moving module(include oil burning system)
4.Hot aggregate elevator(put in cold supply modular during transportation)
5.Dust moving module(include leve one dust collector and draught fan chimney)
6.Mix tower mobile module
7.Filter supply mobile module(include filter elevator)
8.Bitumen supply mobile module(include thermal oil furnace system)
9.Set aside type finished product bin (optional)
10.Air circuit system
11. Electrical control system

B. Equipment technical index
1.Capacity(standard condition): 100t/h;
2.Fuel consumption(standard condition):6-7kg/t;
3.Operation type: Manual, semi-automatic, full automatic;
4.Power cnfiguration list.

Trailer type Mobile Asphalt Plant For Sales 100t/h,120t/h

SPECIFICATIONS FOR 80 TON MOBILE ASPHALT HOT MIXING PLANT
cold agg system	Cold aggregate bin	4 unit
	Belt feeder	Consistence: inclined belt feeder, oversize screen	Inclined belt feeder equipped with emergency stop and pull switch
	Electrical control system	One set	Rated operation condition
drying system	Dry drum	Diameter: 1800mmX8500mm, capacity: 120t/h
	Burner	Diesel/heavy oil	Burner equipped with gas ignition, has high ignition success rate. Medium atomization, sufficient burning.
	Dust moving module	Bag house dust collection	Adopts downstream injection mode, has good dust removal effect, make the service life longer.
Mix tower mobile module	Hot aggregate elevator	Diesel/heavy oil
	1 set three layers semi-structure vibration screen(monopodium outlay) Four insulation warehouse	Weighting system adopts single bin, 4 pints hang, with transport fixed components, Double inducer drive, twin shaft reverse rotation mixing tank.	weighting capacity: aggregate 800kg, powder 100kg, bitumen 80kg.
	Mineral powder supply system	Consistence: filter elevator, new and recycle powder bin, filter weighting device, two sets screwconveyor.	Screw conveyor exit equipped with butterfly valve, to control the impulse;filter temporary storage bin pneumatic break arch

After-Sales Service

1.Pre-sales Services:

Contact - Design - Discussion (email/call/chatting tools) - Offer - Visiting Invitation & Reception - Establish Primary Trust

2. Selling Services:

Sending the confirmed design and foundation map for building foundation;
Taking photos and videos of the production processes for customers’ reference
Pre-assemble main parts together and test
Paint color and Logo following customers’ requirements;
Arrange customers to come to inspect the finished goods;
lBook the shipping space in advance to ensure delivery on time.
Monitor containers loading and packing, such as wooden boxes packing, steel wires reinforcement.

3. After-sales Services:

Tracking the vessels and the estimated arriving date;
Sending all necessary documents and assist to fetch the goods smoothly;
Dispatch experienced engineers to installation & commission, and training;
Regularly learning the equipment running situation;
Remote control is available at any time;
Warranty: 12 months
Spare Parts: sending through DHL/FEDEX/TNT

Please contact us if you are interested in our products ,we will give you response in 24 hours !
