aluminum foil composition materials for Roofing or duct

1. Description  of  aluminum foil composition :

2-way fiberglass Aluminum foil scrim kraft facing/3-way fiberglass aluminium foil scrim kraft/fiberglass fabric coated aluminuim foil ...  with ISO certificated and sgs approved flame retardant materials vendor of SAINT-GOBAIN. Aluminium foil composition materials used for roofing, or wrapping the air-condition ducts and so on.

The  2-way fiberglass Aluminum foil scrim kraft facing is a kind of compounded material with reinforced fiberglass liner to Aluminium foil laminated to kraft paper.

2.Structure of aluminum foil composition :

The main raw materials is aluminum foil, Scrim built from fiberglass yarn and Kraft as substrate.

a)  Aluminum foil: 7μ
b) Adhesive: Flame Retardant

c) 2 - way fiberglass

d)  Kraft: 60gsm(Natural)

e)  Roll width: 1m, 1.2m, 1.25m, 1.30m
f)  Roll length: 60m, 300m, 120m, 500m, 1800m, 3000m
g) Core I.D.: 3"(76mm ±1)
h) Tolerance: Weight and Thickness: ±10%; Width: ±3mm; Length: ±0.5%.

3. Application:

• Metal & Steel Buildings
• Homes
• Roof Underlayments
• Cathedral Ceilings
• Crawl Spaces
• Hot Water Heaters
• Basement Walls
• Floors
• Garage Doors
• Concrete slabs
• Driveway snow melts
• Pole barns
• Post frame buildings
• Poultry barns
• Animal kennels
• Temperature sensitive storage areas
