column-style load cell
- Shenzhen
You May Like
Product Details
| Place of Origin | Guangdong, China | Brand Name | WESTBOAO | |
| Model Number | LC403 | Usage | Pressure Sensor | |
| Theory | Resistance Sensor | Output | Analog Sensor |
Product Description
Specifications
material:alloy steel & stainless steelsurface nickel plated ,correct dislocation automatically
hermatically sealed by laser
Load cell , column-style load cell,weighing load cell
Suitable for electronic truck scales,hopper scales and other electronic weighing devices.
Capacity(t): 10,20,25,30,40,50,100
Common load cell Specifications:
Accuracy grade:C2/C3
Comprehensive error (%F.S) : ±0.03 / ±0.02
Sensitivity (mv/v) : 1.5±0.003
Creep (%F.S/30min) : ±0.023 / ±0.016
Zero output (%F.S) : ±1.0
Input Resistance (Ω): 700±10
Output Resistance (Ω): 700±5
Insulation resistance (MΩ) : ≥5000(100VDC)
Temperature Effect on Zero (%F.S/10): ±0.029 / ±0.019
Temperature Effect on Span (%F.S/10): ±0.017 / ±0.011
Temperature compensation range (°C ) : -10~+40
Operating temperature (°C ) : -20~+55
Excitation voltage (V) : 9~12(DC)
Safe overload (%F.S) : 150
Limit overload (%F.S) : 200
Protection Grade: IP67/IP68
Installation size diagram:
Capacity(t) | H1 | H2 | φA | L | M | SR |
10--20 | 180 | 64.9 | 73 | 99.7 | M36X3 | 200 |
25--30 | 200 | 70 | 88.9 | 115.6 | M42X3 | 250 |
40--60 | 250 | 96.9 | 105 | 138.3 | M56X4 | 300 |
100 | 350 | 126.1 | 152.4 | 183.9 | M76X4 | 400 |
Wire connecting method:
red input +
white output -
black input -
green output +
Power diagram:
