Home > Products > oil regeneration > Chongqing ZSC Used Truck Oil Purifier Series
Chongqing ZSC Used Truck Oil Purifier Series
- Chongqing or Shanghai
- T/T
You May Like
Product Details
| Condition | New | Flow | as per day | |
| Working Pressure | Normal Pressure | Place of Origin | Chongqing, China | |
| Brand Name | Junneng | Model Number | ZSC-15 | |
| Usage | Other, waste engine oil | Voltage | 220~415V | |
| Power(W) | 120KW | Dimension(L*W*H) | 40HQ Container | |
| Weight | 15T | Certification | ISO9001 | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Chongqing ZSC used truck Oil Purifier Series
Through many years hard work, the Company successfully developed the ZSC series engine oil purification and discolourization purifier, which is a breakthrough in oil depolarization a worldwide difficulty. This ZSC engine oil purifier can remove the tiny impurity dispersed in oil such as carbon particles and deep oxides, as well as bad substance such as colloid and bitumen. Thus, the clarity of oil recovered, engine oil quality is improved, performance of engine is restored, abrasion reduced.These would ensure correct operation of lubricant system of an engine and extend the life time of engine oil and engine as well. This kind of purifier is applicable to purification of various engine oil used for transport facilities such as ship and automobile.
Features
1It is a physiochemical application to eliminate the electric charge between polar particulate in waste oil, which is gathered into large particles and separated. The colloid, bitumen and other compound in oil are also removed while harmful gas and the water content are removed by the waste gas cleaner and the vacuum degas function. Thus, the oil is cleaned and the effective constituent of oil is retained.
2High precision stainless steel net is used, which is anti-corrosive, high temperature resistant and has a good mechanical strength and long lifetime. It is easy to use, and utilizes the economical pressure filter as filter medium.
3Novel structure, good layout and is deemed as a Mini Refinery.
4Very straight and evident effect and the machine can be used for multiple purposes.
Technical Parameters
Name | Unit | ZSC-1 | ZSC-2 | ZSC-3 | ZSC-5 | ZSC-6 | ZSC-8 | ZSC-10 | ZSC-15 | ZSC-20 |
capacity | T/8-10 h | 1 | 2 | 3 | 5 | 6 | 8 | 10 | 15 | 20 |
Recovery rate | % | 85~90% | ||||||||
Recycled color |
| ≤3 | ||||||||
Flash point | °C | ≥220( According to deal with the oil depends ) | ||||||||
Total acid | mgKOH/g | ≤0.1 | ||||||||
Filtration precision | μm | ≤5 | ||||||||
Water content | ppm | ≤50 | ||||||||
Working noise | db(A) | 65~85 | ||||||||
Pump pressure | Mpa | ≤0.4 | ||||||||
Power supply | 380V 50HZ( According to the customer's specific requirements to set ) | |||||||||
Heating power | KW | 48 | 60 | 72 | 96 | 115 | 144 | 168 | 255 | 340 |
Total power | KW | 65 | 75 | 90 | 115 | 150 | 165 | 185 | 280 | 368 |
Heating time | Hour | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 |
Filter area |
| 6 | 10 | 15 | 20 | 20 | 25 | 30 | 50 | 60 |
weight | KG | 2600 | 3000 | 3500 | 4500 | 5000 | 5500 | 7200 | 9200 | 11600 |
If you want to know more information about these series, please contact us.
