JNC waste engine oil purifier machine

JNC  waste engine oil purifier machine

1. Overview

This machine can be used in black engine oil, to get gasoline, kerosene and diesel oil through distilled catalyst. Pumping into the heater with Waste oil which can be pretreated, through the coal (or fuel oil) heating to working temperature, and the required gasoline, kerosene and diesel oil can be obtained after catalytic distillation. When the reaction of waste oil in reactor is complete, stop heating, and remove residue from the tank of bottom, then this machine can be used again.

2.Systems of equipment

Reaction tank: waste oil will be pumped into this tank after pretreated.

Heating system: through burning coal or fuel oil to make the oil temperature up to setting value. This system is equipped with insulation system.

Catalytic system: waste oil reaches the predetermined temperature, via catalytic effect, and then the gaseous hydrocarbons will become gasoline, kerosene and diesel composition.

Cooling system: gasoline, kerosene and diesel after catalytic effect can be condensed into liquid materials.

Temperature control system: ensure that waste oil transform into gasoline, kerosene and diesel oil, waste oil drying by distillation, can stop  heating timely.

Exhaust gas handling system: a small amount of not liquefied gas via treated, can meet emission standards.

3. Index of oil after treatment:

Diesel oil: 86-90%,

Gasoline oil: 3-4%,

Kerosene: 2-3%,

Oil residue: 3-4%.

Advantages of the JNC series - used oil catalytic distillation renewable diesel equipment

1, the working principle: the used oil directly in under the action of catalyst distillation get standard diesel;

2, the diesel filter plate and frame provided with machine can, do not need to add acid, alkaline, and clay refining;

3, the catalyst processing waste engine oil per ton cost only 75 yuan;

4, used direct fuel oil or gas heating, convenient, economic, health, peace, environmental protection;

5 is introduced in this paper, the diesel yield is as high as 86-88%, another 5-6%, gasoline residue of 6-8%;

6, our way of heating is heating sealed mixing, not easy to form scale, reduce later consumables and maintenance costs;

7, distillation, currently on the market of heating coil is commonly used in heating, the heating mode, coil easy scaling, cyclic, and high temperature circulating pump is required to play this kind of pump is bad and expensive, high cost of late.
