Spool Insulators Ansi
US$ 0.1 - 0.2
/ Piece
200 Pieces(Min. Order)
- ningbo
- T/T
You May Like
Product Details
| Place of Origin | Zhejiang, China | Brand Name | haivo | |
| Model Number | 53-2 | Type | High Frequency Ceramics | |
| Material | Forsterite |
Product Description
Specifications
1)weight:0.22-1.20kg2)Certificates:ISO9001:2008
3)best price and short delive
ANSI 53 series Spool Porcelain Insulators
1)weight:0.22-1.20kg
2)Certificates:ISO9001:2008
3)best price and short delive
ANSI 53 series Spool Porcelain Insulators
•Material: Porcelain
•standard:ANSI
•class standard:53-1/53-2/53-3/53-4/53-5
•specification:
Cat NO
| A1053 | A1054 | A1055 | A1056 | A1057 | |||
Fig | 2 | 1 | 2 | 2 | 3 | |||
Class ANSI | 531 | 53-2 | 53-3 | 53-4 | 53-5 | |||
Main Dimensions (mm) | H | 54 | 76 | 81 | 76 | 105 | ||
h | 27 | 38 | 40.5 | 38 | 52.5 | |||
D | 57 | 79 | 76 | 105 | 102 | |||
d | 45 | 45 | 45 | 73 | 73 | |||
d 1 | 18 | 18 | 18 | 18 | 18 | |||
d 2 | 22 | 24 | 24 | 24 | 24 | |||
R | 11 | 18 | 11 | 16 | 11 | |||
Mechanical failing load (kn) | 907 | 1360 | 1814 | 2041 | 2722 | |||
Flashover Voltage | Power-frequency | Dry (kv) | 20 | 25 | 25 | 25 | 25 | |
Wet | Upright | 8 | 12 | 12 | 12 | 18 | ||
Level | 10 | 15 | 15 | 15 | 25 | |||
Weight(kg | 0.22 | 0.55 | 0.6 | 1.15 | 1.20 | |||
